Specifications
Waterproofing Of Reinforced Concrete Flat Roof1.High tensile strength,elongation strength
2.Polyester reinforcement PVC
Waterproofing Of Reinforced Concrete Flat Roof
Product Information
PVC roofing membrane is a highly-engineered,new-type membrane manufactured
using polyvinyl chloride as main materials and added other chemicals such as anti-oxidant,anti-UV materials to make it flexible,stable and UV-resistant.
Product Features
- Long using life, aging resistance, the service life is more than 50 years for roofing and underground.
- High tearing strength, high extensibility and the size will have little change after heat treatment.
- Good flexibility at low temperatures and good puncture resistance.
- Easy for application and it is environmentally-friendly.
- Chemical resistance.
Application Range
GB12952-2010
No. |
Test Item |
Indicators |
||
Code G | ||||
1 |
The thickness of resin layer above the reinforcement fabric mm≥ |
0.40 |
||
2 |
Stretching Performance |
Tension Strength Mpa≥ |
10 |
|
Breaking Elongation%≥ |
200 |
|||
3 |
Heating Treatment Size Change Rate%≤ |
0.1 |
||
4 |
Low-temperature Bending |
-25°C No Craze |
||
5 |
Water Impermeability |
0.3Mpa,2h Water Impermeability |
||
6 |
Impact Resistance |
0.5kg·m , Water Impermeability |
||
7 |
Anti-static Load a |
20kg Water Impermeability |
||
8 |
Seam Peel Strength N/mm ≥ |
3.0 |
||
9 |
Right-angle Tear Strength N/mm ≥ |
50 |
||
10 |
water absorption(70°C168h)% |
After Soaking ≤ |
4.0 |
|
After Airing≥ |
-0.40 |
|||
11 |
Heat aging(80°C) |
Time |
672h |
|
Appearance |
No blisters, cracks, delamination, bonding and holes |
|||
Tensile Strength (max. tensile)Retention%≥ |
85 |
|||
Elongation Retention %≥ |
80 |
|||
Cold Bending |
-20°C No Craze |
|||
12 |
Chemical Resistance |
Appearance |
No blisters, cracks, delamination, bonding and holes |
|
Tensile Strength (max. tensile)Retention %≥ |
85 |
|||
Elongation Retention %≥ |
80 |
|||
Cold Bending |
-20°C No Craze |
|||
13 |
Artificial climate accelerating ageing c |
Time |
1500hb |
|
Appearance |
No blisters, cracks, delamination, bonding and holes |
|||
Tensile Strength (max. tensile)Retention %≥ |
85 |
|||
Elongation Retention %≥ |
80 |
|||
Cold Bending |
-20°C No Craze |
|||
