Mining Roof Support Geogrid

Specifications

Geogrid
1.Tensile strength in warp & weft direction;
2.Mesh size:12.7,25.4,50mm.
3.Roll width:1-6M

                             Mining Roof Support Geogrid

Mining Roof Support Geogrid  Introduction

Geogrid reforcing embankment of road/car park/railway/airport  belong to geosynthetics materials that fulfil a reinforcing function in a ground structure. They are formed by a flat polymer structure, namely by a system of mutually perpendicular longitudinal and cross drawn elements which can be bonded continually by weaving, welding, gluing or binding in the points of intersection thus usually creating apertures with sizes between 1 and 10 cm.

This allows penetration of particles of soil/rock or other geotechnical materials through mesh apertures and formation of particle interlocking. It is good for this reinforcing particle interlocking effect when the grains are able to push through the mesh with at least a half of their volume into the substrate layer.

  Mining Roof Support Geogrid are used both for reinforcement of non-cohesive, cohesive soils and formation made of coarse-grained materials.
Mining Roof Support Geogrid   are classified as uniaxial and biaxial grids
Uniaxial grid - strength in the machine direction of reinforcement is predominant
Biaxial grid - strengths in the cross and machine directions of the geogrid are equal



Mining Roof Support Geogrid  Application:



1.Base courses for road, railway, and airport construction

2.Construction of access roads and transportation links

3.Retaining structures and very steep banks

4.Slope stabilization

5.Noise-protection embankments

6.Contaminated land reclamation

7.Piled embankments

8.Landfill construction

9.Bridging of hollows and sink holes

  Mining Roof Support Geogrid Specifiation:



Specification		EVA1×1	EVA1×1	EVA1×1	EVA1×1	EVA1×1	EVA2×2	EVA2×2
Strength	Long . Horiz	≥30	≥50	≥60	≥80	≥100	≥60	≥80
		≥30	≥50	≥60	≥80	≥100	≥60	≥80
Percentage of Elongation		4%	4%	4%	4%	4%	4%	4%
Size of Hole mm		25.4×25.4	25.4×25.4	25.4×25.4	25.4×25.4	25.4×25.4	12.7×12.7	12.7×12.7
Flexibility		76	76	76	76	76	76	76
Width M		1--6	1--6	1--6	1--6	1--6	1--6	1--6
Temperature		-100200	-100200	-100200	-100200	-100200	-100200	-100200





Pls feel free to contact us:
