Specifications
HDPE Geogrid PriceCreep
Temperature Stability
Chemical and Physical Stability
Tensile strength: 25-260kn/m
HDPE Geogrid Price
HDPE Geogrid Price Description:
HDPE Geogrid is widely used in civil construction over the whole world. It is manufactured on the basis of high-impact polyethylene and polypropylene. Geogrids are used as reinforcement materials on mellow soils for railway and car roads, parking places, landing grounds and for the reinforcement of bridge piers, slopes and earth banks, for erosion protection of slopes .
HDPE Geogrid Price Feature:
1. Reduce costs- apertures designed to work with wide range of fill allowing for the use of
less expensive soils
2.Reduce depth of excavation required on unsuitable sub grades
3. Increase developable areas without incurring cost of unattractive and expensive retaining wall
4. Stabilizing slopes increases the strength of soil giving it a higher factor of safety and greater
seismic durability
5.Reduces maintenance and extends the life of the pavement by reducing differential settlement
of roadways
6. Durability – high resistance to soil micro-organisms and chemicals, UV radiation and mechanical damage
7. forms a composite mechanics limited system when asphalt concrete goes through the structure
HDPE Geogrid Price Application:
1.Base courses for road, railway, and airport construction
2.Construction of access roads and transportation links
3.Retaining structures and very steep banks
4.Slope stabilization
5.Noise-protection embankments
6.Contaminated land reclamation
7.Piled embankments
8.Landfill construction
9.Bridging of hollows and sink holes
10.Reinforcement of highways slopes and higher steepness slopes fixation;
11.Bed fixation of the various types of road surfacing;
12.Reinforcement of littoral zone of water reservoirs and greek beds;
13.Fixation of the railroad cone slopes;
14.Support wall construction
HDPE Geogrid Price Index:
Index Properties |
Units |
MD Values |
XMD Values |
Aperture Dimensions |
mm(in) |
25(1.0) |
33(1.3) |
Minimun Rib Thickness |
mm(in) |
1.27(0.05) |
1.27(0.05) |
Tensile Strength @2% Strain |
KN/m(lb/ft) |
6.0(410) |
9.0(620) |
Tensile Strength @5% Strain |
KN/m(lb/ft) |
11.8(810) |
19.6(1,340) |
Ultimate Tensile Strength |
KN/m(lb/ft) |
19.2(1,310) |
28.8(1,970) |
Junction Efficiency |
% |
93 |
|
Flexural Stiffness |
Mg-cm |
750,000 |
|
Aperture Stability |
m-N/deg |
0.65 |
|
Resistance to Installation Damage |
%SC/%SW/%GP |
95/93/90 |
|
Resistance to Long Term Degradation |
% |
100 |
|
Resistance to UV Degradation |
% |
100 |
Pls feel free to contact us:
