Specifications
HDPE Geocell For Retaining WallWelded Distance : 330mm-1000mm
material:HDPE
Cell depth:50mm 75mm 100mm 150mm 20
HDPE Geocell For Retaining Wall
Product Description
Cellular Confinement System Price is made of welding high tensile HDPE broad bands. It has many cells and is very flexible.
- Slope Protection
- Channel Protection
- Load Support
- Earth Retention
- Markets
Product Installation Method
1.Unfolding the geogrid (Some fiber-material can be put under the geogrid according to the concrete condition,for example geotextile and felted cushion.)
2.Fixing it with nail or connecting with the frame of stretcher;
3.Used loader to fill with filler until it is full top and beyond of the geogrid, then through vibration
and rolling, the subbase is completed
4.By now, the system of geogrid can prop up kinds of construction equipment, and that construction directly above it is accepted, together with conventional manner surface
Item No. | Hight | Weld distance | Thickness of the Sheet | Tensile Strength of Welding Points | Tensile Strength of Connection of Cells | Tensile Strength at Yield of Each Sheet |
GS-50-400 | 50 | 330≤A<1000 | ≥1.1 | ≥100 | ≥120 | ≥20 |
GS-75-400 | 75 | 330≤A<1000 | ≥1.1 | ≥100 | ≥120 | ≥20 |
GS-100-400 | 100 | 330≤A<1000 | ≥1.1 | ≥100 | ≥120 | ≥20 |
GS-150-400 | 150 | 330≤A<1000 | ≥1.1 | ≥100 | ≥120 | ≥20 |
GS-200-400 | 200 | 330≤A<1000 | ≥1.1 | ≥100 | ≥120 | ≥20 |
Remarks: Width of the product can be made according to the customer’s demand, and other special standards will carry out by agreement or contract | ||||||
