Aquaculture Water Purification geo Dewatering bag geotube
Geotube systems are large tubular geotextile bags that allow the dewatering of a liquid waste and the containment of the sludge residue containment in a single, low-cost operation. Waste volume reduction can be as much as 90%, making solids removal and disposal easy.
Geotube containers are available in a variety of sizes, depending on volume and space.
Aquaculture Water Purification geo Dewatering bag geotube
Physical properties |
Test Method |
Unit |
Value |
Unit weight |
ASTM D 5261 |
g/m2 |
355(+-5%) |
Color |
|
|
white |
Width |
|
M |
3.4-3.75 |
Mechanicalproperties |
|
|
|
Tensile Strength MD |
ASTM D 4595 |
KN/M >= |
55 |
Tensile Strength CD |
ASTM D 4595 |
KN/M >= |
70 |
Enlongation at break MD |
ASTM D 4595 |
% <= |
28 |
Enlongation at break CD |
ASTM D 4595 |
% <= |
25 |
CBR puncture strength |
ASTM D 6241 |
KN/M >= |
7.2 |
Hydraulic properties |
|
|
|
Pore opening size 090(095) |
ASTM D 4751 |
mm |
0.1-0.5 |
Permeability |
ASTM D 4491 |
|
|
UV resistance |
|
cm/s |
(3-5)*10-2 |
Other colors are availible |
70% Strength retained after 500 hours |
|
|
Aquaculture Water Purification geo Dewatering bag geotube
Geotube systems are used for environmental protection and remediation dewatering applications.
•Environmental dredging
•Industrial wastewater processing
•Mining and mineral processing
•Municipal applications
•Agriculture
4. Geotube used in breakwater
How it works?
1. Filling - The sludge is filled into the Geotube container. Environmentally safe polymers are added to the sludge, which make the solids bind together and water separate.
2. Dewatering - Solids are captured by the container while clear effluent water drains from the container. The filtrate can be collected and recirculated through the system.
3. Consolidation - When full, the container and contents can be deposited at a landfill, or the solids removed and land-applied when appropriate.
1. We are a high -new technology enterprise which mainly produce and deal with Geo synthetics product. You are welcomed to our factory any time .
2.Our material have pass the quality inspection system before delivery,was proved good quality easy construction by many projects.
3. We ensure provide the best quality and short delivery time for costumers .
4. We have professional service team.
5. Our excellent team would be very happy to work with you and offer suggestions,product applications, and design assistance.
HONGXIANG products are widely used in national key engineering fields, such as water conservancy, railway, subway, highway, landfill, anti-seepage, construction industry, mining industry, agriculture, ecological greening system, etc. engineering fields, and exported to United States, Russia, Pakistan, Thailand, Tanzania, Australia, South Africa, Zambia, United Arab Emirates etc. more than 30 countries and regions.
