Hebei huiya Full auto foaming mould,floral foam resin equipment
- 100 Set / Sets per Month
- China port
- Credit Card
You May Like
-
Hebei huiya Industrial Grade,Chemical Grade standard floral foam machine
-
Hebei huiya resin synthesis equipment& floral foam auto-machine& foaming mould
-
Hebei huiya Auto floral foam making machine,raw materials,technology transfer
-
Hebei huiya the latest equipment and formulation for making floral foam
-
Hebei Huiya High Pressure Big Flowing Floral Foam Machine
-
floral foam in decorative flowers
Product Details
Condition | New | Product Type | Foam Net | |
Place of Origin | Hebei, China | Brand Name | HuiYa | |
Model Number | HY | Voltage | 220V | |
Power(W) | 22KW | Dimension(L*W*H) | 3.35X1.9X2.3m | |
Weight | 1600KGS | Certification | CE | |
Warranty | 12 months except spare parts | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Full auto foaming mould,floral foam resin equipment
Product Purpose: Wet Floral foam, Dry Floral Foam.
Product Feature:
1. Our company adopts solid paraformaldehyde synthesis technology, solve the sewage problem and
environment protection, etc.
2. Using electric heating and physical reaction combined with automatic temperature control system, improve
the production efficiency, reduces the resin to produce cost, synthetic resin equipment combined with automatic foaming
machine, let the stability of the foam (density, strength, water absorption, water retention, PH) come true, and let the foam open porosity rate can
reach more than 95%. New technology of the production cost was reduced by 15% than old technology.
3. The whole production line includes resin synthesis equipment, floral foam machine, vertical cutting machine
and printing machine, etc.
1.Electrical heating reaction vessel
Product features:
1. Principle: the principle of electrical heating the reaction kettle is insert electric heater in the jacketed heat
conduction oil, using thermal oil as medium is introduced into the wall of a kettle, make the material inside the kettle is heated
response. Reaction pot consists of pot, stainless steel tube body, jacket, mixer, shaft sealing device and bearing, shaft
sealing device is divided into packing seal and mechanical seal
2. Characteristics:
1) can be according to customer request custom anchor type wheel, impeller, pan, pusher, or box type mixing
form, as well as the mixing of different combinations.
2) can be customized according to customer requirements of various kinds of heat exchanger, including jacket,
coil, electric heating, steam heating, heat conduction oil heating
3) optional explosionproof performance, sealing performance, positive pressure and negative pressure in various configurations
4) due to a large number of design, manufacture, sale of nonstandard stirred tank, accumulated a wealth of industry experience, to customers' requirements
More understand the hole quantity, specifications or other requirements, can according to user requirements
design, processing production separately.
2.Two Component Floral Foaming Machine
Product Feature:
1. Main unit: Material injection by a precision needle valve, which is taper sealed, never worn, and never
clogged; the mixing head produces complete material stirring; precise metering (by a precision metering pump);
single button operation for convenient operation; switching to a different density or color at any time.
2. Control : Microcomputer PLC control; TIAN electrical components exclusively imported to achieve the goal for
automatic, accurate and reliable control can be imputed with more than 500 working position data; pressure, temperature
rotation rate digital tracking and display and automatic control; abnormity or fault alarm devices. Import converter (PLC) can
control eight different product ratio.
Equipment model | HY-803 |
Source | Total power 22KW,4*220V/60HZ |
Suit foam type | Phenol aldehyde flower mud |
Injection flow | 1500g-2500g/S note: the size of flow can be set |
Injection pressure | 0.1MPA-3.99MPA |
Mix ratio | 100-15;100-30 |
viscosity(22 ) | Resin 500-3000MPAS |
viscosity(22°C) | Acidic curing agent 500-2000MPAS |
Feeding time | 0.01-99.9/S(accuracy 0.01S) |
Injection materials Precision | 0.1/100 |
Injection procedure number | PLC program manual injection |
Pneumatic work pressure | 0.6-0.8MPa |
Floor space | Wide 5M height 3.2M |
Overall weight | 1.8t |
Mixed casting head | Use ball value type |
PLC Programming Computer Chinese show(Taiwan Delta) | can control 100 different mould (product) pouring quantity at the same time, can automatic cleaning machine |
Heating system | Can automatic control temperature |
3.5KW water cycle vacuum pump and storage tank | A set |
10P refrigeration unit | A set |
3.Foaming mould
Product Feature:
Using automatic electrical heating temperature control system, make floral foam heated evenly, temperature is consistent.
And make floral foam forming rules, uniform density, hardly any waste generated.
4.Cutting machine and Printing machine
Product features: computer control, simple operation. Equipped with suction machine, greatly reduces the floral foam
powder pollution, make working environment more healthy.
Shipping Packaging:seaworthy packing ,general is bare .
Our service: You can coming to our factory to learn ,and our general manager also can to your place to teach you.our warranty period is one year,but we will be tracking service when your machine have something wrong or other happens.
Hebei Huiya Floral Foam Special Equipment Co., Ltd. was founded in 2015, which is located in DingZhou City, Hebei Province. Xuzhou Huiya Imp.&Exp. Co., Ltd. was founded in 2012, which is located in Xuzhou City, Jiangsu Province.
Our company is engaged in the export of floral foam, floral foam production line and other energy-saving products. At the beginning, the company went through business hardships and depression of the market, which makes the enterprise enjoy rapid growth. With the help of good management, we have established a good enterprise image. Our company insists on the principle of Quality First, Reputation Foremost, Constant Improvementto do business with the clients home and abroad. Our company is doing the best to provide new and old customers with high-quality product and service.
In the process of continuous research and practice,we updated the production technology and production equipment and overcame the disadvantages and manual production equipment.We not only reduced the process if resin dehydration ,but also realized the continuous automatic foaming.The improvements achieve automatic production,which can greatly reduce the production cost,enhance the product quality and make product quality stable and easy to control,solve the problems of environment protection and pollution.
We fully engage in developing the market of automatic production of floral foam home and abroad .
Our products have been exported to many countries.We have exported our machine and technology to India,Indonesia, Venezuela, Pakistan Vietnam, Kazakhstan, Armenia, Russia, Iran,Turkey,Mexico etc.
The good quality and service have earned us good reputation from customers. Sincerely welcome the new and old customers.
We sincerely wish that we could establish a long and friendly business relationship with more companies home and abroad.
1.Can I get free samples? |
YES. We would like to send several samples for your reference if you could afford freight. |
2.What surface handing could you support ? |
We can provide help buyer print logo on the foam and carton. |
3.Do you accept customized order ? |
YES. We can arrange opening the mould according to customers’ requirement. |
4. What is the normal lead time ? |
(1). For stock products, we will send goods to you within 12-24hours after we receive your payment. (2). For surface handing products, the delivery time is within 7-10 work days after we receive your payment. |
5. What is your selection of shipping method ? |
(1). For small trial order, international express, just as UPS, FedEx, TNT, EMS, DHL is suitable. (2). For large order, we can arrange shipment by sea or air according to your requirement. |
6.How do you control the quality ? |
We do 3 times leakage test before packing. |
7.If any defective floral foam, how do you deal with ? |
We have 1:1 replacement for the defective floral foam. |
8.Which trade terms do you prefer? |
We can accept FOB, C&F, CIF,etc. |
9.What's your Payment terms? |
T /T, Western Union, etc. |
We sincerely hope that we could establish a long friendly business relationship with more
companies home and abroad.
