Hebei Huiya Reactor of Making the Phenolic Resin
- tianjin port
- Credit Card
You May Like
-
Factory Price Customized Floral Foam Vertical Cutting Machine
-
Customized Floral Foam Production Machine
-
Factory Sale Wet Floral Foam Making Production Line
-
Hebei Huiya Floral Foam Machine & Reactor of Product the Resin
-
Hebei Huiya Full Automatic Floral Foam Machine
-
Hebei Huiya Full Automatic Floral Foam Production Line & Moulding Machine
Product Details
| Condition | New | Product Type | Foam Net | |
| Brand Name | HUIYA | Model Number | HY-1008 | |
| Voltage | 380V/50HZ | Power(W) | 30kw | |
| Dimension(L*W*H) | 2*4*3M | Weight | 1.9T | |
| Certification | CE | Warranty | 12 Months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Resin synthesis equipment
This equipment adopts the material:304L、Q235 :
(1) Energy saving: the production of 700 kg resin used electric 50 RMB, don't need to be heated in the process of production, It was synthesized by chemical physics, compared with other production of foam equipment greatly reduces the cost of production.
(2 ) Environmental protection: no sewage,no waste emissions;
(3) Efficient: 1000 l reactor can produce 700 kg resin, production time 4 hours
(4) the total power configuration: 22 w, actual use power: 6 kw;
Foaming Equipment
Description: (1) material: 304 L, Q235
(2) energy saving, high efficiency, environmental protection equipment, PLC control
(3) the ability of 15 to 20 seconds to 1 m3 after speed: 2800 revolutions per minute
(4) after installation equipment specification: 5.8 M * 2.6 M * 3.5 M
(5) the total power rating: 26.8 KW, the actual average operating power is about 1.05
Semi-finished products mold
Description: (1) the mold specifications: 1 cubic (can be customized according to customer's requirements)
(2) one mold specifications: inner diameter 1 M * 1 M* 1 M
(3) automatic constant temperature setting, time control systems,
(4) three mold after installation equipment specifications: 5.8 M * 1.6 M * 1.6 M length: 13 M
(5) the total power rating: 24 kw
Vertical cutting machine
Description: (1) the peel and cut different shape of the bubble specifications;
(4) after installation equipment specification: 3.6 M * 2.8 M * 2.4 M wide
(5) the total power rating: 1.5 KW
CNC horizontal cutting machine
Description:This equipment is CNC automatic operation, and the vertical cutting machine the staff work together, a woman can operation, ability to work in accordance with the eight hours can cut 2000-2200-8 cm specification foam box bubble.
(1) 8 cm foam cutting specifications;
(2) after the installation equipment specification: 5.6 M * 2.8 M * 2.4 M
(3) the total rated power: 4.5 KW
PLC Horizontal pushing printing machine
Description: (1)23 cm, 11 cm size cutting,
(2) printing (LOGO),
(3) the PH treatment system
(4) after installation equipment specification: 5.8 M * 8.6 M * 1.3 M wide
(5) the total power rating: 0.5 KW
(6) production capacity: 8 hours can produce 1500 cartons of foam.
1.Can I get free samples?
YES. We would like to send several samples for your reference if you could afford freight.
2.What surface handing could you support ?
We can provide help buyer print logo on the foam and carton.
3.Do you accept customized order ?
YES. We can arrange opening the mould according to customers’ requirement.
4. What is the normal lead time ?
(1). For stock products, we will send goods to you within 12-24hours after we receive your payment.
(2). For surface handing products, the delivery time is within 7-10 work days after we receive your payment.
(3). For products we never manufactured , we could open the mould if needed.
5. What is your selection of shipping method ?
(1). For small trial order, international express, just as UPS, FedEx, TNT, EMS, DHL is suitable.
(2). For large order, we can arrange shipment by sea or air according to your requirement.
6.How do you control the quality ?
We do 3 times leakage test before packing.
7.If any defective floral foam, how do you deal with ?
We have 1:1 replacement for the defective floral foam.
8.Which trade terms do you prefer?
We can accept FOB, C&F, CIF,etc.
9.What's your Payment terms?
T /T, Western Union, etc.
