Hebei Huiya Two- Group Automatic Foaming Machine

Hebei Huiya Two- Group Automatic Foaming Machine thumbnail-1
Hebei Huiya Two- Group Automatic Foaming Machine thumbnail-2
Hebei Huiya Two- Group Automatic Foaming Machine thumbnail-3
Hebei Huiya Two- Group Automatic Foaming Machine thumbnail-4
Hebei Huiya Two- Group Automatic Foaming Machine photo-1
Hebei Huiya Two- Group Automatic Foaming Machine photo-2
Hebei Huiya Two- Group Automatic Foaming Machine photo-3
Hebei Huiya Two- Group Automatic Foaming Machine photo-4
US$ 125,000 - 130,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Foam Net
Place of Origin:
Hebei, China
Contact Supplier Request Quote Chat Now
Xuzhou Huiya Imp.&Exp. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Product Type Foam Net
Place of Origin Hebei, China
Brand Name HY
Model Number HY
Voltage 380V/50HZ
Power(W) 30kw
Dimension(L*W*H) 2*4*3m
Weight 3900kgs
Certification CE
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Resin synthesis equipment

(1) Energy saving
(2 ) Environmental protection: no sewage,no waste emissions
(3) Efficient: 1000 l reactor can produce 700 kg resin, production time 4 hours
(4) the total power configuration: 22 w, actual use power: 6 kw

Foaming Equipment

 (1) material: 304 L, Q235
(2) energy saving, high efficiency, environmental protection equipment, PLC control
(3) the ability of 15 to 20 seconds to 1 m3 after speed: 2800 revolutions per minute
(4) after installation equipment specification: 5.8 M * 2.6 M * 3.5 M
(5) the total power rating: 26.8 KW, the actual average operating power is about 1.05

Foam Mould

(1) the mold specifications: 1 cubic
(2) one mold specifications: inner diameter 1 M * 1 M* 1 M
(3) automatic constant temperature setting, time control systems
(4) three mold after installation equipment specifications: 5.8 M * 1.6 M * 1.6 M length: 13 M
(5) the total power rating: 24 kw

Vertical cutting machine

(1) the peel and cut different shape of the bubble specifications
(4) after installation equipment specification: 3.6 M * 2.8 M * 2.4 M wide
(5) the total power rating: 1.5 KW

CNC horizontal cutting machine

(1) 8 cm foam cutting specifications
(2) after the installation equipment specification: 5.6 M * 2.8 M * 2.4 M
(3) the total rated power: 4.5 KW

Horizontal pushing printing machine

(1)23 cm, 11 cm size cutting
(2) printing (LOGO)
(3) the PH treatment system
(4) after installation equipment specification: 5.8 M * 8.6 M * 1.3 M wide
(5) the total power rating: 0.5 KW
(6) production capacity: 8 hours can produce 1500 cartons of foam.


Detailed Parameters
Name
Size(m)
Weight(T)
Power
Packaging
Voltage
Frequency
Material
Volume
Remarks
Reactor
2*2*3
1T
/
/
380 volts
50HZ
304 stainless steel thickness:6mm
1000L actually can use 800L
Tank
2*2*3
0.9T
/
/
380 volts
50HZ
304 stainless steel thickness:6mm
1000L actually can use 800L
Dissolv tank
2*1*0.9
/
/
2PCS
380 volts
50HZ
/
/
4PCS of heater,2tanks ,one tank have two pcs of heater
Electric machinery
/
/
5.5KW
2PCS(reactor and tank have each one)
380 volts
50HZ
/
/
Heaters
/
/
4KW
4PCS
380 volts
50HZ
/
/
Screw feeder
/
/
1.5KW
1PC
380 volts
50HZ
/
/
the reactor more than screw feeder than tank
Vacuum pump
/
/
5.5KW
380 volts
50HZ
/
/
Water pump
/
/
2.2KW
380 volts
50HZ
/
/
Resin pump
/
/
1.5KW
380 volts
50HZ
/
/
container cabinet
1.65*0.55*1.4
0.055
/
1PC
380 volts
50HZ
/
/
Name
Size(m)
Weight(T)
Power
Packaging
Voltage
Frequency
Material
Volume
Remarks
foaming machine(A)
0.38*0.22*0.22
1T
4
1PC
380 volts
50HZ
A:304 stainless steel thickness:6mm
800L
foaming machine(B)
0.38*0.22*0.22
1T
1.1
1PC
380 volts
50HZ
B:PP material thickness:12mm
400L
Gear pump(A)
5.5KW
Gear pump(B)
2.2KW
Nose
4.0KW
Name
Size(m)
Weight(T)
Power
Packaging
Voltage
Frequency
Material
Volume
Remarks
Mould
1.30*1.10*1.40
1.3T
380 volts
50HZ
Windlass
0.5KW
Heater
3KW
carbon steel
Inside of mould
thickness:10mm
Outside of mould
thickness:6mm
Product Flow Chart
Packing & Delivery
Related Products
Customer visit
Factory Pictures
FAQ

1.Can I get free samples?
YES. We would like to send several samples for your reference if you could afford freight.
2.What surface handing could you support ?
We can provide help buyer print logo on the foam and carton.
3.Do you accept customized order ?
YES. We can arrange opening the mould according to customers’ requirement.
4. What is the normal lead time ?
(1). For stock products, we will send goods to you within 12-24hours after we receive your payment.
(2). For surface handing products, the delivery time is within 7-10 work days after we receive your payment.
(3). For products we never manufactured , we could open the mould if needed.
5. What is your selection of shipping method ?
(1). For small trial order, international express, just as UPS, FedEx, TNT, EMS, DHL is suitable.
(2). For large order, we can arrange shipment by sea or air according to your requirement.
6.How do you control the quality ?
We do 3 times leakage test before packing.
7.If any defective floral foam, how do you deal with ?
We have 1:1 replacement for the defective floral foam.
8.Which trade terms do you prefer?
We can accept FOB, C&F, CIF,etc.
9.What's your Payment terms?
T /T, Western Union, etc.
