1HP Solar Powered DC Air Conditioner Without Inverter

1HP Solar Powered DC Air Conditioner Without Inverter thumbnail-1
1HP Solar Powered DC Air Conditioner Without Inverter thumbnail-2
1HP Solar Powered DC Air Conditioner Without Inverter photo-1
1HP Solar Powered DC Air Conditioner Without Inverter photo-2
US$ 700 - 900 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Model Number:
NG-26GW/DC
Specification:
Normal
Application:
Home
Contact Supplier Request Quote Chat Now
Guangzhou Neerg Eco Technologies Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Model Number NG-26GW/DC
Specification Normal
Application Home
Output Voltage (V) 48VDC
Load Power (W) 570W
Solar Power (W) 1200W
Work Time (h) 6 hours

1P Solar DC Air Conditioner



1HP Solar Powered DC Air Conditioner without inverter

Main Features:

*Power Specification:48V DC

* Driven by solar panels directly, no inverter required, no AC power required.

* R134a CFC free refrigerant, Eco-friendly

* 100% driven by solar energy, 100% energy saving

* hybrid mode available after match with power adaptor.

* Minimum energy loss, SEER>19

* The operation is convenient and simple

*.Intelligent Defrost,Independent Dehumidification,Sleep Mode,Quiet Operation;

*.Auto—protection,Auto Restart; And High Efficiency Ventilation.

*.Offering cooling only and cooling&heating for choices

*.Sleeping Model,Infrared Ray Long Distance Remote Control,Breakdown Self-Check;

*.It is provided with the microcomputer control technique

*.Self-protection function



Model NG-26GW/DC NG-35GW/DC NG-50GW/DC
Power supply 48V DC  48V DC  48V DC
Cooling Capacity                      Btu/h 9000(1P) 12000(1.5P) 18000(2P)
Input            W 570 900 1100
Rated current    A 11.88 18.75 18.33
EER         W/W 4.56 3.88 4.54
Heating
(optional)		 Capacity         Btu/h 9000(1P) 12000(1.5P) 18000(2P)
Input            W 570 900 1100
Rated current    A 23.75/11.88 37.5/25/18.75 22.9/18.33
COP        W/W 4.56 3.88 4.54
Compressor Power 48V DC  48V DC  48V DC
Indoor air flow (Hi/Mi/Lo) m3/h 460/390/340 500/400/350 780/700/550
Indoor noise level (Hi/Mi/Lo) dB(A) 37/34/31 42/39/36 46/43/40
Indoor unit Dimension(W*D*H) mm 710x189x250 790x190x275 940x198x275
Packing   (W*D*H) mm 775x260x324 865x265x350 1015x265x350
Net/Gross weight   Kg 7.5/9 9/11 10/13.5
Outdoor air flow             m3/h 1300 1900 2000
Outdoor noise level         dB(A) 51 54 56
Outdoor unit Dimension(W*D*H) mm 685x260x430 700x235x535 780x250x540
Packing  (W*D*H) mm 795x345x495 815x325x580 910x335x575
Net/Gross weight   Kg 22.5/24.5 25/27 33/36
Refrigerant type g R134/430g R134/560g R134/900g
Connection wiring     1.5(Optional ) 1.5(Optional) 1.5(Optional )
Connection copper pipe m 3(6.0mm&9.52mm) 3(6.0mm&9.52mm) 3(6.25mm&12.7mm)
Thermostat type Remote control Remote control Remote control
Operation temp               ℃ 17-30 17-30 17-30
Application area             m2 11-16 16-26 25-42
Solar Panel W 1200 1600 2000
Lead-acid battery Ah 400 800 1200



1HP Solar Powered DC Air Conditioner without inverter
