High Speed Double Layer Steel Reels and Bobbins for Cable and Wire
US$ 75 - 90
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
Baohong
Place of Origin:
China
Model Number:
PND 630
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
30 days
Related Products
-
China 2017 Rigid Frame Wire Stranding Machine With Good PriceUS$ 100000 - 200000MOQ: 1 Set -
Cable Machine - Rigid Type Stranding Machine for Power CableUS$ 100000 - 200000MOQ: 1 Set
-
JCJXKJ500 Cable Rigid Frame Stranding MachineUS$ 100000 - 200000MOQ: 1 Set
-
Rigid Frame Stranding MachineUS$ 100000 - 200000MOQ: 1 Set
-
Rigid Stranding Machine/Rigid Strander (driven by Independent Motor)US$ 100000 - 200000MOQ: 1 Set
Brand Name
Baohong
Place of Origin
China
Model Number
PND 630
Usage
Other, Take-up tools for wire and cable
1.Price low, saving your costs
2.on time delivery
3.high speed winding
4.Reliable strength
5.Enhanced durability
Technical parameter for reference
In accordance with GB4004-83, JB/T7600.3-94 and DlN46395 standards, the product is made of common carbon steel Q235 thick plate through assembly and welding, and machine finishing. The product has high rigidity of bobbin and high precision. Through dynamic test, the product has stable operation at high speed, and can be used for high-speed drawing-wire machine and wire stranding machine.
| Serial Number | Specification Model | Lateral Plate Diameter D1 | Major Diameter D2 | Axle Hole Diameter D4 | Carrying Hole Diameter D5 | Center Distance E of Axle Hole and Carrying Hole | External Width L1 | Internal Width L2 |
| 1 | 400 | 400 | 224/250 280 | 125/127 | 28 | 100 | 265 300 | 224 250 |
| 2 | 500 | 500 | 280/315 355 | 125/127 | 28 | 100 | 300 375 | 250 315 |
| 3 | 560 | 560 | 315/355 400 | 125/127 | 28 | 100 | 355 425 | 280 355 |
| 4 | 630 | 630 | 355/400 450 | 125/127 | 28 | 100 | 375 475 | 315 400 |
| 5 | 710 | 710 | 400/450 500 | 250 | 40 | 170 | 425 530 | 355 450 |
| 6 | 800 | 800 | 450/500 560 | 250 | 40 | 170 | 475 600 | 400 500 |
| 7 | 1000 | 1000 | 560/630 710 | 250 | 50 | 250 | 750 | 630 |
| 8 | 1250 | 1250 | 710/800 900 | 250 | 50 | 250 | 950 | 800 |
We can produce spools accordance with customer's sample and drawing
