Drilling diameter 110 325mm diameter
Drilling depth 350m
Adapting to rock hardness f=6 - 20
Working pressure 1.2 - 4MPa
Consumption of Air Volume 16 - 50m3/min
Rotational speed of power head 30; 61; 81; 162; 123; 325r/min
Power head maximum torque 6000Nm
Power head maximum lifting force 25T
Lifting speed 0-3.82m/min (stepless speed regulation); 9.55m/min (fast)
Power head maximum plus pressure 12.8T
Pressure speed 0-7.49m/min (stepless speed regulation); 18.7m/min (fast)
Pressure lifting cylinder stroke 3500mm
Power head Max stroke 7000mm
Minimum ground height 250mm
Hoisting tool 1.5T
Hoisting speed of 20m/min tool
Tool for winding wire rope diameter Phi 10mm
The hoisting capacity of 50m tools
Walking speed 2km/h
Climbing angle 25
Diesel engine R6105ZD, 84KW (boost), 1500r/min
Generator (optional) 15KW
Dimensions (length * width * height) 4000 * 2090 * 2760 (transportation condition)
Weight 8500Kg
