Help CenterCrawler Crane Type Drilling Rig
Related Products
Depth of drilling (m) 300-600
Drill pipe diameter (mm) of phi 42, Phi 50
The vertical speed (r/min) is: 70; 121; 190; 263; 329; 570; 899; 1241
Inversion: 55; 257r/min
Max torque (Nm) 2760
The maximum vertical lifting force (KN) 72
Max feeding force (KN) 54
The vertical stroke (mm 600)
The vertical diameter of the through hole (mm) with 68
Single rope hoist the maximum lifting force (KN) 30
The diameter of wire rope / rope capacity (mm/m) with 16/50
Lifting speed (m/s) 0.41-1.58
Power configuration (KW) motor Y180L-4 (22)
Diesel engine 4100 (40)
Shift travel (mm) 465
Transport dimension (length * width * height) (mm) 6500 * 2000 * 3320
Whole machine quality (kg) 5960
Derrick height (m) 7.7
Nominal size (length * width) (mm) 2800 * 2800
Rig adjustment angle (DEG) 45-90
