12V 24V 36V to 24v 6a Waterproof Boost&buck DC-DC Power Converter

Dezhou Greatway Import And Export Co., Ltd.
12V 24V 36V to 24v 6a Waterproof Boost&buck DC-DC Power Converter thumbnail-1
12V 24V 36V to 24v 6a Waterproof Boost&buck DC-DC Power Converter thumbnail-2
12V 24V 36V to 24v 6a Waterproof Boost&buck DC-DC Power Converter thumbnail-3
12V 24V 36V to 24v 6a Waterproof Boost&buck DC-DC Power Converter thumbnail-4
12V 24V 36V to 24v 6a Waterproof Boost&buck DC-DC Power Converter photo-1
12V 24V 36V to 24v 6a Waterproof Boost&buck DC-DC Power Converter photo-2
12V 24V 36V to 24v 6a Waterproof Boost&buck DC-DC Power Converter photo-3
12V 24V 36V to 24v 6a Waterproof Boost&buck DC-DC Power Converter photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
gw
Model Number:
GW9-40S2406
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name gw
Model Number GW9-40S2406
Output Power Other, 144w
Output Type Other, single and dual
Size 74*74*32mm
Weight 0.32kg
Input Voltage 9v~40V
Output Voltage 24v
Type DC/DC Converters
Output Current 6A
Product Description

 12V 24V 36V to 24v 6a waterproof boost&buck DC-DC power converter12V 24V 36V to 24v 6a waterproof boost&buck DC-DC power converter

Features:

1. 100% full power & stable current output

2. 100% Imported components

3. Wide input voltage from 8-40Vdc

4. Industry grade DC8-40V to DC12V step-down converter, high efficiency up to 95%

5. 100% waterproof & anti-shock protection, Ultra compact size, light weight

6. According: CE/RoHS, IP68 design

7. Die-cast aluminum shell, epoxy potting, Cooling by free air convection

8. Protections: Over-current, Over-voltage, Over-temperature, Over-load and Short-circiut. Auto-recovery when device is back to normal operating

9. Non-Isolated Module,

Applications:

Trucks,Golf Carts,Forklifts,Buses,Loaders,Logging Vehicles,Wind Power System,Solar Power System,Electromotor,Telecommunications,Boat & Yacht,and so on...



Specifications:







Model

GW8-40S1206

Input rated voltage

12V/24V/36V DC

Input voltage range

9-40V DC

Efficiency

90% (half load), 86% (full load)

Output voltage

24V DC

Output current

06Amps

Output rated power

144Watts

Output peak power

130%

Voltage regulation

< 1%

Load regulation

< 2%

Ripple (Full load test)

< 150mV

No-load current

< 25mA

No-load loss (Watt)

0.72 ~ 1.44

Working temperature

-30℃~ +80℃

Waterproof rating

IP68

Over-voltage protection

YES

Over-current protection

YES

Over-temperature protection

YES

Short-circuit protection

YES

Machine size

74*74*32mm

Package size

98*82*34mm

N. Weight

290g

G. Weight

300g

Heat dissipation method

Die-cast aluminum housing

Natural heat dissipation







Packaging & Shipping

 12V 24V 36V to 24v 6a waterproof boost&buck DC-DC power converter











Company Information

 12V 24V 36V to 24v 6a waterproof boost&buck DC-DC power converter



our   company specialized in the manufacture and export of electric system products ,  including,pure sine wave power inverter, motor controller,charger,DC-DC converter,electronic throttle,battery discharge indicator ,air conditioning system,electric system solution .etc





 12V 24V 36V to 24v 6a waterproof boost&buck DC-DC power converter
