48v to 24v 40a 960w Waterproof Buck Dc-dc Power Converter

Dezhou Greatway Import And Export Co., Ltd.
48v to 24v 40a 960w Waterproof Buck Dc-dc Power Converter thumbnail-1
48v to 24v 40a 960w Waterproof Buck Dc-dc Power Converter thumbnail-2
48v to 24v 40a 960w Waterproof Buck Dc-dc Power Converter thumbnail-3
48v to 24v 40a 960w Waterproof Buck Dc-dc Power Converter thumbnail-4
48v to 24v 40a 960w Waterproof Buck Dc-dc Power Converter thumbnail-5
48v to 24v 40a 960w Waterproof Buck Dc-dc Power Converter photo-1
48v to 24v 40a 960w Waterproof Buck Dc-dc Power Converter photo-2
48v to 24v 40a 960w Waterproof Buck Dc-dc Power Converter photo-3
48v to 24v 40a 960w Waterproof Buck Dc-dc Power Converter photo-4
48v to 24v 40a 960w Waterproof Buck Dc-dc Power Converter photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
GW
Model Number:
GW-48S24R40
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name GW
Model Number GW-48S24R40
Output Power Other, 960W
Output Type Single
Size 180*127*63mm
Weight 1.65KG
Input Voltage DC 36-60V
Output Voltage DC 24V
Type DC/DC Converters
Output Current 40A



Product Description

 48v to 24v 40a 960w waterproof buck dc-dc power converter48v to 24v 40a 960w waterproof buck dc-dc power converter



Our products are widely used in automotive, posts and telecommunications, communications, electricity, coal, aerospace, defense, surveillance systems, railway signals, medical equipment, instruments and meters, LED displays, cable TV and other fields.
Features:
1. 100% full power & stable current output
2. 100% Imported components
3. Wide input voltage from 36-60Vdc
4. Industry grade DC48V to DC24V step-down  converter, high efficiency up to 96%
5. 100% waterproof & anti-shock protection, Ultra compact size, light weight
6. According: CE/RoHS, IP68 design
7. Die-cast aluminum shell, epoxy potting, Cooling by free air convection
8. Protections: Over-current, Over-voltage, Over-temperature, Over-load and Short-circiut. Auto-recovery when device is back to normal operating
9. Non-Isolated Module,
10. 1 year warranty, lifetime up to 100,000 hours.

48v to 24v 40a 960w waterproof buck dc-dc power converter





Specifications:



Specifications:

Model

GW-48S24R50

Input rated voltage

48V DC

Input voltage range

36-60V DC

Efficiency

97% (half load), 96% (full load)

Output voltage

24V DC

Output current

40 Amps

Output rated power

960Watts

Output peak power

130%

Voltage regulation

< 1%

Load regulation

< 2%

Ripple (Full load test)

< 300mV

No-load current

40mA

Working temperature

-35°c ~ +80°c

Waterproof rating

IP68

Over-voltage protection

YES

Over-current protection

YES

Over-temperature protection

YES

Short-circuit protection

NO

Machine size

180*127*63MM

Package size

200*135*75MM

N. Weight

1.55kg

G. Weight

1.65kg

Cooling way

Free air convection

Other

Carton packaging

Packaging & Shipping

 48v to 24v 40a 960w waterproof buck dc-dc power converter

 48v to 24v 40a 960w waterproof buck dc-dc power converter
