Help Center700w/1.5kw/2kw/3kw/4KW 6kw/8kw Lithium Iron Battery Charger With CANBUS Communication
Related Products
-
8000w Electric Vehicle Lithium Battery ChargerNegotiableMOQ: 1 Piece -
4KW HF/PFC on Board Lithium Battery Charger for Electric CarNegotiableMOQ: 1 Piece
-
HF/PFC on Board Lithium LiFePO4/LiMn2O4 Battery Charger for Electric CarNegotiableMOQ: 1 Piece
-
1.5kw/2kw/3kw/4kw/6kw/8kw Lithium LiFePO4 Battery Charger for Electric CarNegotiableMOQ: 1 Piece
-
1.5kw/2kw/3kw/4kw/6kw/8kw Lithium Battery Charger for Electric CarNegotiableMOQ: 1 Piece
chargers are programmed to your specifications and shipped from the Elcon facility in California. Please provide me with your zip code so I can provide an accurate quote on shipping.
A sealed 2500 W charger with an output voltages range from 24VDC to 320VDC and current range from 40A to 5A. Output current is dependent on input voltage and output voltage selected with maximum power being 1500W
1. Free custom programming to your exact requirements included with every charger. Also free email technical support and half-price reprogramming for the life of the charger.
2. Internal integrated PFC, no pollution to electric network, minimizes disturbance on electric network from heavy current.
3. Wide input voltage range AC85V~AC265V available for worldwide requirements, convenient for electric-network fluctuation and vehicles exportation.
4. High efficiency, above 93%, while traditional chargers can meet only about 80% efficiency.
5. Intelligent temperature compensation function in the charging process, preventing damage to the battery caused by charge-off or charge due, greatly extending the lifespan of the battery.
6. Fully-sealed and water-proof, protection class IP46. Shock resistance treatment made inside makes vibration-proof level up to SAEJ1378 that can fully meet the standard of automobile appliance usage.
7. Available for various kind of LiFePO4 batteries. Flexible and programmable charging module. Ability to select 10 different Amp Hour or Cell Count settings. Equipped with CAN communication interface to realize real-time communication with BMS.
|
Lead acid Battery charger |
Lithium Battery charger |
Output voltage Nominal |
Output voltage Maximum |
Output current Maximum |
GWCH-48-70 |
GWCH-H66-70 |
48V |
66V |
70A |
GWCH-60-60 |
GWCH-H82.6-60 |
60V |
82.6V |
60A |
GWCH-72-50 |
GWCH-H96.2-50 |
72V |
96.2V |
50A |
GWCH-84-42 |
GWCH-H112-42 |
84V |
112V |
42A |
GWCH-96-36 |
GWCH-H130-36 |
96V |
130V |
36A |
GWCH-108-32 |
GWCH-H144.7-32 |
108V |
144.7V |
32A |
GWCH-120-30 |
GWCH-H168-30 |
120V |
168V |
30A |
GWCH-144-24 |
GWCH-H192-24 |
144V |
192V |
24A |
GWCH-156-22 |
GWCH-H208-22 |
156V |
208V |
22A |
GWCH-168-20 |
GWCH-H233.3-20 |
168V |
233.3V |
20A |
GWCH-180-18 |
GWCH-H243-18 |
180V |
243V |
18A |
GWCH-192-18 |
GWCH-H258-18 |
192V |
258V |
18A |
GWCH-216-16 |
GWCH-H289.5-16 |
216V |
289.5V |
16A |
GWCH-240-14.2 |
GWCH-H337-14.4 |
240V |
337V |
14.2A |
GWCH-288-12 |
GWCH-H389-12 |
288V |
389V |
12A |
GWCH-312-11 |
GWCH-H417-511 |
312V |
417V |
11A |
|
Lead acid Battery charger |
Lithium Battery charger |
Output voltage Nominal |
Output voltage Maximum |
Output current Maximum |
GWCH-48-140 |
GWCH-H66-140 |
48V |
66V |
140A |
GWCH-60-120 |
GWCH-H82.6-120 |
60V |
82.6V |
120A |
GWCH-72-100 |
GWCH-H96.2-100 |
72V |
96.2V |
100A |
GWCH-84-84 |
GWCH-H112-84 |
84V |
112V |
84A |
GWCH-96-72 |
GWCH-H130-72 |
96V |
130V |
72A |
GWCH-108-64 |
GWCH-H144.7-64 |
108V |
144.7V |
64A |
GWCH-120-60 |
GWCH-H168-60 |
120V |
168V |
60A |
GWCH-144-48 |
GWCH-H192-48 |
144V |
192V |
48A |
GWCH-156-44 |
GWCH-H208-44 |
156V |
208V |
44A |
GWCH-168-40 |
GWCH-H233.3-40 |
168V |
233.3V |
40A |
GWCH-180-36 |
GWCH-H243-36 |
180V |
243V |
36A |
GWCH-192-36 |
GWCH-H258-36 |
192V |
258V |
36A |
GWCH-216-32 |
GWCH-H289.5-32 |
216V |
289.5V |
32A |
GWCH-240-28.8 |
GWCH-H337-28.8 |
240V |
337V |
28.8A |
GWCH-288-24 |
GWCH-H389-24 |
288V |
389V |
24A |
GWCH-312-22 |
GWCH-H417-22 |
312V |
417V |
22A |
