Help CenterHF/PFC on Board Lithium LiFePO4/LiMn2O4 Battery Charger for Electric Car
Related Products
-
1.5kw/2kw/3kw/4kw/6kw/8kw Lithium LiFePO4 Battery Charger for Electric CarNegotiableMOQ: 1 Piece -
1.5kw/2kw/3kw/4kw/6kw/8kw Lithium Battery Charger for Electric CarNegotiableMOQ: 1 Piece
-
700w li Iron / Lithium Polymer HF Battery ChargerNegotiableMOQ: 1 Piece
-
700w li Iron / Lithium Polymer HF Battery ChargerNegotiableMOQ: 1 Piece
-
1.5kw/2kw/3kw/4kw/6kw/8kw HF/PFC On-board Charger for Electric CarNegotiableMOQ: 1 Piece
Specifications
LiMn2O4 battery charger ,adopts advanced high frequency switching mode power supply technology2.light weight, compact
Feature Overview
The charger is applicable for various lithium batteries like LiFePO4, LiMn2O4 etc.,hemicolloid hemicolloid
It features light weight,small volume, stable performance, high efficiency and reliable security etc.,
The charger is widely used for battery-charging cycles in electric vehicles such as electric forklift, golf cars,
electric trucks, electric tour bus, electric yacht, cleaning machines, or Uninterruptible Power Supply (UPS),
solar energy, wind power dynamo and electric communication system on the railway etc.
Specifications
1. Thermal Self-Protection: When the internal temperature of the charger exceeds 75°C, the charging
current will reduce automatically. If it exceeds 85 °C , the charger will shutdown protectively. When the
internal emperature drops, it will resume charging automatically.
2. Short-circuit Protection: When the charger encounters unexpected short-circuit, it will automatically
stop to output. When fault removes, the charger will re-start in 10 seconds.
3. Reverse Connection Protection: When the battery is polarity reversed, the charger will cut off the
connection between the internal circuit and the battery, and refuses to start. It can avoid any destroy.
4. Input Low-voltage & Over-voltage Protection: When the AC input Voltage is lower than 85V or
higher than 265V, the charger will shutdown protectively and automatically resume working with the
voltage is normal again.
Type Table
