144V DC Electric Scroll Compressor of Air Conditioning

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Model Number:

DLCT144

Dezhou Greatway Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name GW

Model Number DLCT144

Size 132*82*40

Type Compressor

Car Make electric car

air conditioning system(A/C) for electric car

a/c system included the following parts

1.Scroll Compressor

2. The condenser assembly

3.A/C controller

4. Air conditioning pipe(line)

5. evaporator

Item			Specifications
Model			Integral type DLCT144-1.6
Cooling mode			Compressor suction cooling
Speed	Range		4000r/min
	Regulation speed		1000r/min /s
	Time of reaching Maximum speed		within 5 seconds after starting
Waterproof			IP67
Control mode			Sine wave control
Operating voltage range			130V-190
Withstand voltage range			Less than200V
Under voltage protection			128V
Under pressure recovery			130V
Over voltage protection			190V
Over voltage recovery			188V
Working current		Normal working maximum current	15A
		Overload operation	The driver detects the load greater than 15A, and the compressor will be shut down
		Motor minimum operating speed	When Motor speed is less than 1000 rpm, the compressor will be shut down
Using environment		Storage temperature	-20 Degree ~65 Degree
		Using temperature	-10 Degree ~ 65 Degree
		Drive belt work surface temperature	30 degrees higher than the ambient temperature
Insulation			More than 50M
