Glove Box |
Dimensions: 1200mm(L) x 750mm(W) x 900mm(H) . Case Material: Stainless Steel 304 with 3mm thickness.Removable Front Window Panel |
Chamber Condition |
Water concentration: |
|
Air-lock Antechamber |
One Main antechamber Dimensions: 360mm(Dia.) x 600mm(L) One Mini-Chamber Dimensions (for tools): 150 mm(Dia.) x 300mm(L) |
Lighting |
fluorescent lamp （in front of box） |
Control system |
Siemens PLC control system with 6" touch screen display H2O: 0 - 1000 ppm with an accuracy of 0.1 ppm; O2: 0 - 1000 ppm with an accuracy of 0.1 ppm Pressure: -2500 to 2500 Pa with an accuracy of 1 Pa |
Gas Purification System |
Automated Regeneration Process Automated water and oxygen removal Purification |
Purging System |
Automatic Purging System allows easy operating and reduce gas consumption |
Glove |
One pair; size 9 3/4" butyl glove is included for immediate use |
Glove Ports |
2ports (materials:Aluminum alloy); size:220mm(Dia.) |
Height of support |
950mm |
KF40 port |
9 sets |
Tray |
2 layers/3layers |
Filter system |
2sets, Inlet and Outlet filter can eliminate particle size > 0.3 μm |
Containment |
1.2m3 |
Welding method |
Inward/outward flange |
Gas Purification System Model |
GP20 |
Application |
Remove O2 & H2O |
Column |
Single column |
Purification capacity |
3M3 |
Filling material |
10kg/column (Copper Catalyst & Molecular Sieve) |
Removal capacity |
H2O: 1000g; O2: 30L |
Regeneration gas capacity |
3000L |
Regeneration gas |
5-10%H2 &95-90% N2 or Ar |
Cooling system |
Water cooled 3-5L/min |
Vacuum pump |
Britain EDWARDS RV-12 pump is included for faster vacuum and removing moisture |
Leak rate |
|
Working Voltage |
220V AC 50/60Hz, 10A, Single Phase |
BNC |
DN40 |
Shipping Dimension |
86" x 45" x 91" (6.8M3) |
Shipping Weight |
650 kg (1400 lbs) |
Warranty |
One Year limited warranty with lifetime support Rusting and damage due to improper storage condition or maintenance is not covered by warranty |
Option |
1.Purification System（GP200）double columns 2.Internet of things（IoT) function |
