pets/snacks/soya protein food extrusion
Series of Double_screw Inflating extrusion are consisting of feeding system, extruding system, cutting system, heating system, Gearing system and controlling system.
1.Consists of feeding system extruding system and cutting system, adopts frequency speedcontrolling with high automation and stable per-formation.
Main features:
Rich raw materials: such as rice, corn, millet, wheat, oats, buckwheat, bean, and starch
Diverse products: such as various fallow foods, core-filled foods, grain gruel, nutrient powder, and bread crumbs
Stable performance: adopting imported frequency or electromagnetic controlling system, high automation and smooth operation Permanent working life: with special material and technology, the screw and nut involved can work continuously for one year under conditions of high wear and pressure
Feeding system:
Spiral feeding, forced conveying, full mixing, unnecessary for moisture adjustment to ingredients, and adjustable speed of conveying
Extruding system:
The working principle is forcing the ingredients forward to be conveyed and extruded in the sealed charging barrel by making use of the engaged twin screws, at the same time, heating the ingredients through heating-cycles, the ingredients are mixed, melt and sheared step by step under the conditions of high temperature and pressure. At last the ingredients are inflated at the point of being extruded out. This system possesses self-cleaning function.
Rotary-cutting system:
The ingredients are cut by high-speed rotary cutting-off knife when they are extruded and inflated. The length of cut-off is adjustable through step-less speed regulating electrical machine.
Heating system:
The heating system is divided into several heating areas by means of far-infrared heating-cycles. The temperature of each area is automatically adjusted through separate temperature controller.
Driving system:
This system is composed of primary electric motor, reductor, distribution box, and lubrication system. Adopting imported frequency controller, it assures large regulating range, efficient power distribution, accurate adjustment, steady working as well as prolonging the working life of the components.
Controlling system:
Adopting centralized controlling, the whole process, from starting, rotary cutting, lubricating, switching off to output adjustment can be automatically operated. Automatic defender and status display device are also allocated in this system Digital display for pressure control in extruding system and temperature in heating
2. Automatic lubricating, cooling, to guarantee the extruder running safely.
3.According to different material, to choose the relative single or double screw feeding system, the material should be uniformity and stable.
4. Screw is made by special technique, is able to bear grinding, steady and reliable, longer using life.
5. According to different screw design rate to full different technology request.
It can produce various fallow foods, snacks, core-filled foods, grain gruel, nutrient powder, pet food, soya nuggets food, soya protein foods. Furthermore, this equipment is widely utilized in the fields of fodder making, chemical industry, wine making, and pharmacy.
Series of Doublecrew Inflating Extruder are consisting of feeding system, extruding system, cutting system, heating system, Gearing system
and controlling system.
Model CY65-II
Installed capacity 35KW
Power consumption 28KW
Output 120-150KG/H
Size 2.5×1×1.8m
