90W Poly Silicon Solar Module /100watt Solar Panel With Outlet/130W Solar Module
US$ 0.56 - 0.7
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
XIHE 100W solar panel
Model Number:
100W solar module
Material:
Polycrystalline Silicon
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
250W Poly Silicon Solar Module /260watt Solar Panel With Outlet/275W Solar ModuleUS$ 0.56 - 0.7MOQ: 1 Piece -
285W Poly Silicon Solar Module /285watt Solar Panel With OutletUS$ 0.56 - 0.7MOQ: 1 Piece
-
300W Poly Silicon Solar Module /300watt Solar Panel With OutletUS$ 0.56 - 0.7MOQ: 1 Watt
-
250W Poly Silicon Solar Module,solar Panel With High Efficiency/grade A Solar ModuleUS$ 0.56 - 0.7MOQ: 10 Pieces
-
95W Mono Silicon Solar Panel With ISO ,TUV,CEUS$ 0.6 - 0.8MOQ: 10 Pieces
Brand Name
XIHE 100W solar panel
Model Number
100W solar module
Material
Polycrystalline Silicon
Size
1488*664*35mm
Number of Cells
36
Max. Power
100W
Product Description
90W /100W/130W polycrystalline silicon solar module
Polycrystalline Solar Module
XH90WP(36)/ XH100WP(36)/ XH130WP(36)
Models | XH250P(36) | XH275P(36) | XH300P(36) |
Max. Power (Pmax) | 90Wp | 100Wp | 130Wp |
Optimum Operating Voltage (Vm) | 17.6V | 17.4V | 17.3V |
Optimum Operating Current (Im) | 5.12A | 5.75 A | 7.12A |
Open-circuit Voltage (Voc) | 21.7V | 21.6V | 22.6V |
Short-circuit Current (Isc) | 5.58A | 6.31 A | 7.85A |
Cells efficiency | 15.8% | 15.2% | 15.0% |
Dimension L×W×H (mm) | 998*664*35 156*104 | 1131*664*35 156×119 | 1488×664×35 156×156 |
Power Tolerance (Pmax) | 0 ~ +3% | 0 ~ +3% | 0 ~ +3% |
Numbers of cells | 32 pcs poly solar cell | 36 pcs poly solar cell | 36pcs poly solar cell |
weight | 8.2kg | 9kg | 12kg |
Max system voltage | 1000V DC | 1000V DC | 1000V DC |
Temperature cycling range | -40℃ ~ +85℃ | -40℃ ~ +85℃ | -40℃ ~ +85℃ |
