air conditioner for outdoor cabinets OC SERIES

Model OC03 OC06 OC08 OC10 OC15 OC20 OC25 OC30 OC40

cooling capacity W 300 600 800 1000 1500 2000 2500 3000 4000

Btu/h 1023 2050 2730 3406 5120 6825 8532 10238 13651

power supply 220-240V/1PH/50Hz / 110-120v/1ph/60Hz

rated power 210 290 464 750 1030 1360

Grade of Protection inside  IP55

outside  IP34

Refrigergerant R134a

Ambient temp (-40°C-55°C)

Inside temp 25°C-40°C

temperature controller set point(°C) temp range:25°C-40 °C factory settings :35°C

fan 2 pcs *EBM fan

Installation Door mounting/wall Side mounting

Noise(A) 60 61 61 62 62 63 63 64 65

Height(mm) 470 750 1100 1100 1100 1100 1300 1300 1350

Width(mm) 350 430 430 430 430 430 430 430 620

Depth(mm) 185 195 195 195 195 240 270 270 350

...
