cooling kiosk1.48vdc,220/110vac cooling for telecom cabient cooling capacity form 300W-1000W
cooling kiosk
Our cabinet air conditioner is a professional thermal control solutions provider for outdoor cabinets. it is has accumulated rich technological and application experience in this field. The DC OR AC Air Conditioner series is the result of technology applied in battery and solar powered outdoor cabinet. The product use DC or AC powered compressor and fans, so the whole system can also work in those areas that have no AC power or when the AC power is failed.
The SYSTEM is a compact, high efficiency DC OR AC powered air conditioner.
The design is optimized for applications with limited space available, but where functionality and performance still cannot be compromised.
Ø 48VDC air conditioner
Ø 340W cooling capacity 25ºC /35ºC
Ø 520W cooling capacity 35ºC /35ºC
Ø Compact design
Ø Door mounted - easy integration in outdoor cabinets and enclosures
Ø Wide working temperature range (-15ºC to +55 ºC)
BENEFITS
Ø Reliable and high quality cooling system
Ø Cost effective design
Ø Easy installation in outdoor and indoor cabinets
Ø Lifetime >10 years - minimum maintenance
Ø Environmental friendly - R134A and RoHS compliant
Ø Safe and burglar proof design
Ø Resistant to corrosive environments - IP55 and Salt fog tested
Ø Cooling settings
Ø Protection for high voltage
APPLICATIONS
Ø Outdoor Battery Cabinets
Ø Outdoor Radio Base Stations / Telecom Cabinets
Ø Outdoor Solar Powered Telecom Cabinets
Ø Outdoor Power Supply Cabinets
Ø Outdoor Wind Power Control Cabinets / Shelters
Ø Outdoor Gen-set Control Cabinets / Shelters
Indoor Battery Cabinets / Shelters
air conditioner for outdoor cabinets OC SERIES
Model
OC03
OC06
OC08
OC10
OC15
OC20
OC25
OC30
OC40
cooling capacity
W
300
600
800
1000
1500
2000
2500
3000
4000
Btu/h
1023
2050
2730
3406
5120
6825
8532
10238
13651
power supply
220-240V/1PH/50Hz / 110-120v/1ph/60Hz
rated power
210
290
464
750
1030
1360
Grade of Protection
inside
IP55
outside
IP34
Refrigergerant
R134a
Ambient temp
(-40°C-55°C)
Inside temp
25°C-40°C
temperature controller set point(°C)
temp range:25°C-40 °C factory settings :35°C
fan
2 pcs *EBM fan
Installation
Door mounting/wall Side mounting
Noise(A)
60
61
61
62
62
63
63
64
65
Height(mm)
470
750
1100
1100
1100
1100
1300
1300
1350
Width(mm)
350
430
430
430
430
430
430
430
620
Depth(mm)
185
195
195
195
195
240
270
270
350
