Product Details
| Place of Origin: | Shanghai, China | Brand Name: | YUAO | Model Number: | EC05 |
Product Description
Specifications
cabinet type air conditioner,cabinet type air conditioner,battery room air conditionercabinet type air conditioner,cabinet type air conditioner,battery room air conditionerbattery cabinet air conditioner48VDC,rodio base station air conditioner 48VDC,tele cabinet air conditioner48VDC 1.exclusive teachnical 48VDC rotor compressor air conditioner . 2. best solution of 48vdc system air cooling unit DC Air Conditioner | |||||
| it is a professional thermal control solutions provider for outdoor cabinets. it is has accumulated rich technological and application experience in this field. The DC Air Conditioner series is the result of technology applied in battery and solar powered outdoor cabinet. The product use DC powered compressor and fans, so the whole system can also work in those areas that have no AC power or when the AC power is failed. | |||||
| The DC05CDNC1A-A is a compact, high efficiency DC powered air conditioner. | |||||
| The design is optimized for applications with limited space available, but | |||||
| where functionality and performance still cannot be compromised. | |||||
| Ø 48VDC air conditioner | |||||
| Ø 340W cooling capacity 25ºC /35ºC | |||||
| Ø 520W cooling capacity 35ºC /35ºC | |||||
| Ø Compact design | |||||
| Ø Door mounted – easy integration in outdoor cabinets and enclosures | |||||
| Ø Wide working temperature range (-15ºC to +55 ºC) | |||||
| Bitmap Bitmap | |||||
| Ø Reliable and high quality cooling system | |||||
| Ø Cost effective design | |||||
| Ø Easy installation in outdoor and indoor cabinets | |||||
| Ø Lifetime >10 years – minimum maintenance | |||||
| Ø Environmental friendly – R134A and RoHS compliant | |||||
| Ø Safe and burglar proof design | |||||
| Ø Resistant to corrosive environments – IP55 and Salt fog tested | |||||
| Ø Cooling settings | |||||
| Ø Protection for high voltage | |||||
| APPLICATIONS | |||||
| Ø Outdoor Battery Cabinets | |||||
| Ø Outdoor Radio Base Stations / Telecom Cabinets | |||||
| Ø Outdoor Solar Powered Telecom Cabinets | |||||
| Ø Outdoor Power Supply Cabinets | |||||
| Ø Outdoor Wind Power Control Cabinets / Shelters | |||||
| Ø Outdoor Gen-set Control Cabinets / Shelters | |||||
| Ø Indoor Battery Cabinets / Shelters | |||||
| TECHNICAL DATA – STANDARD CONFIGURATION | |||||
| MODEL NO | EC-05 | ||||
| PRICE (FOB SHANGHAI ) | |||||
| Cooling Capacity & Operational Data | |||||
| Cooling Capacity@L35 / L35 | W | 520 | |||
| Cooling Capacity@L25 / L50 | W | 340 | |||
| Internal Airflow | M3/h | 240 | |||
| External Airflow | M3/h | 370 | |||
| Power Consumption@L25/L50 | W | 190 | |||
| Power Consumption@L35/L35 | W | 205 | |||
| Power, Frequency & Range | |||||
| Input Voltage | VDC | -48 | |||
| Frequency | N/A | ||||
| Key Components | |||||
| Controller | Envicool | ||||
| Fans | Telecom Level | ||||
| Compressor | Telecom Level | ||||
| Heater (Optional) | W | N/A | |||
| External Materials | |||||
| Sheet Metal Parts (Optional) | Aluzinc+ Powder | ||||
| Color (Optional) | RAL | 7035 | |||
| Dimensions, Weight & Mount | |||||
| External Dimensions (Height x Width x Depth) | mm | 550×320×170 | |||
| Weight | kg | 11 | |||
| Mounting Method | Door Mounted | ||||
| Application | Outdoor / Indoor | ||||
| Environmental Protection & Performance | |||||
| Working Temperature Range | ºC | -15 to +55 | |||
| Noise Level | dB(A) | 60 | |||
| Protection from Dust, Water and Wind Driven Rain | IP | 55 | |||
| Refrigerant | R134A | ||||
| CE | Yes | ||||
