Telecommunications Cabinet Air Conditioner48VDC,telecom Cabinet Air Conditioner48VDC,enclosure Base Station Air Conditioner48VDC

Telecommunications Cabinet Air Conditioner48VDC,telecom Cabinet Air Conditioner48VDC,enclosure Base Station Air Conditioner48VDC thumbnail-1
Telecommunications Cabinet Air Conditioner48VDC,telecom Cabinet Air Conditioner48VDC,enclosure Base Station Air Conditioner48VDC photo-1
US$ 1 - 1,000 MOQ: 50 Sets
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
YUAO
Model Number:
DC-05
Contact Supplier Request Quote Chat Now
Shanghai Yuao Refrigerant Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name YUAO
Model Number DC-05
Design Rotatable
Display Color Color
Camera No Camera
Operation System Other

Specifications

telecommunications cabinet air conditioner48VDC,telecom cabinet air conditioner48VDC,enclosure Base station air conditioner48VDC

telecommunications cabinet air conditioner48VDC,telecom cabinet air conditioner48VDC,enclosure Base station air conditioner48VDC

telecommunications cabinet air conditioner48VDC,telecom cabinet air conditioner48VDC,enclosure Base station air conditioner48VDC

 1.exclusive teachnical   48VDC rotor compressor  air conditioner .

 2. best  solution of  48vdc  system air cooling unit

DC Air Conditioner

 it is a  professional thermal control solutions provider for outdoor cabinets. it is has accumulated rich technological and application experience in this field. The DC Air Conditioner series is the result of technology applied in battery and solar powered outdoor cabinet. The product use DC powered compressor and fans, so the whole system can also work in those areas that have no AC power or when the AC power is failed.
The DC05CDNC1A-A is a compact, high efficiency DC powered air conditioner.
The design is optimized for applications with limited space available, but
where functionality and performance still cannot be compromised.
Ø         48VDC air conditioner
Ø         340W cooling capacity    25ºC /35ºC
Ø         520W cooling capacity    35ºC /35ºC
Ø         Compact design
Ø         Door mounted – easy integration in outdoor cabinets and enclosures
Ø         Wide working temperature range (-15ºC to +55 ºC)
Bitmap Bitmap
Ø         Reliable and high quality cooling system
Ø         Cost effective design
Ø         Easy installation in outdoor and indoor cabinets
Ø         Lifetime >10 years – minimum maintenance
Ø         Environmental friendly – R134A and RoHS compliant
Ø         Safe and burglar proof design
Ø         Resistant to corrosive environments – IP55 and Salt fog tested
Ø         Cooling settings
Ø        Protection for high voltage
APPLICATIONS
Ø         Outdoor Battery Cabinets
Ø         Outdoor Radio Base Stations / Telecom Cabinets
Ø         Outdoor Solar Powered Telecom Cabinets
Ø         Outdoor Power Supply Cabinets
Ø         Outdoor Wind Power Control Cabinets / Shelters
Ø         Outdoor Gen-set Control Cabinets / Shelters
Ø         Indoor Battery Cabinets / Shelters

TECHNICAL DATA – STANDARD CONFIGURATION
MODEL NO EC-05
PRICE (FOB SHANGHAI )
Cooling Capacity & Operational Data
Cooling Capacity@L35 / L35   W 520
Cooling Capacity@L25 / L50   W 340
Internal Airflow   M3/h 240
External Airflow   M3/h 370
Power Consumption@L25/L50   W 190
Power Consumption@L35/L35  W  205
Power, Frequency & Range
Input Voltage   VDC -48
Frequency   N/A
Key Components
Controller   Envicool
Fans    Telecom Level
Compressor    Telecom Level
Heater (Optional)   W N/A
External Materials
Sheet Metal Parts (Optional)    Aluzinc+ Powder
Color (Optional)  RAL  7035
Dimensions, Weight & Mount
External Dimensions (Height x Width x Depth)  mm  550×320×170
Weight kg 11
Mounting Method    Door Mounted
Application    Outdoor / Indoor
Environmental Protection & Performance
Working Temperature Range  ºC -15 to +55
Noise Level dB(A) 60
Protection from Dust, Water and Wind Driven Rain  IP  55
Refrigerant    R134A
CE   Yes
PictOld
DIMENSIONS


....
