PAN carbon fiber cloth
- 10000 Square Meter / Square Meters per Month
- China port
- Credit Card
- 3K 1500D Kevlar Carbon Fiber And Aramid Woven Mixed Fabric
- 3K 240gsm Honeycomb Hexagon Carbon Fiber Fabric Cloth Materials
- 3k UD Prepreg Carbon Fiber Fabric
- High-Strength 3k 2x2 Twill Weave Carbon Fiber Fibre Prepreg Fabric
- 3K Plain Weave Carbon Fibre Fabric
- 3k 6k 12k Twill Weave Carbon Fiber Fabric Cloth Price
Product Details
Supply Type: | In-Stock Items | Material: | 100% Carbon Fiber | Style: | Plain |
Feature: | Abrasion-Resistant, Heat-Insulation | Use: | Blanket, Felt, Industry | Thickness: | according to requirement |
Place of Origin: | Heilongjiang, China | Brand Name: | J&X | Model Number: | JX-PCC |
Product Description
1.Introduction
The carbon cloth is woven by the PAN-based carbon fiber with characteristics of high electrical conductivity excellent heat insulation ability and ideal structural strength. It's divided into heating carbon fabric,heat insulation carbon fabric and structural strengthening carbon fabric. It also can be used as the reinforced material in carbon/carbon composite products.
2.Technical data
Specification | Temperature | ||||||
Item | Unit | Value | Process temperature | °C | 1450 | ||
Carbon content | % | >98.5 | Operating temperature | In the air | °C | <400 | |
Surface density | g/m2 | 3k:150-180 6k:300-350 12k:500-550 | In the vacuum | °C | >2200 | ||
In the inert atmosphere | °C | >3200 | |||||
Thermal Conductivity | 1050/°CW/(m.k) | 0.17-0.21 | Dimension | ||||
Electric resistance | Ω/mm2 | 40 | Thickness | 3k:0.3mm 6k:0.5mm 12k:0.7mm | |||
Tensile strength | Mpa | >500 | Width | 30-1500mm | |||
Elongation | % | 1.5 | Length | 50-100m | |||
Ash | % | <1.5 | Package | Wooden case | |||
