Carbon Fiber Sheet and Cloth for Reinforcement

US$ 14 - 14 MOQ: 100 Square Meters

Key Specifications

Supply Type:

Make-to-Order

Material:

Other, 100% Carbon Fiber, Carbon Fiber

Style:

Other, plain and twill

Heilongjiang J & X Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port

Delivery Detail:

Delivery time depends on order quantity.

Supply Type Make-to-Order

Material Other, 100% Carbon Fiber, Carbon Fiber

Style Other, plain and twill

Feature Anti-Static, Heat-Insulation

Use Bag, Industry, Other

Place of Origin Heilongjiang, China

Thickness 1.2/1.4

We have four specifications as following : 5cm × 1.2mm, 10cm × 1.2mm, 5cm × 1.4mm, 10cm × 1.4mm

1.Product Characteristics

1.High tensile strength, corrosion resistance, anti-seismic, shock resistance and other good properties.

2.Light weight and excellent flexibility

3.Easy to construct and ensure the quality

4.Favorable durability and corrossion resistance

2.Application Fields:

(1)Anti-bending in concrete beam, anti-shear strength and reinforcement in

bridge board and concrete floorslab.

(2) Concrete, bricky walls, shear wall reinforcement;

(3) Bridge pier, stake and so on reinforcement;

(4) Chimney, tunnel, pool and concrete pipe reinforcement.

3. Technical Index

Model	MKT-I	MKT-II
Thickness	1.2/1.4	1.2/1.4
Type of carbon fiber	T-700-12k	T-300-12k
Tensile strength(Mpa)	≥2800	≥2000
Modulus of elasticity	≥1.65 x 105	≥1.4 x 105
Elongation at break(%)	≥1.7	≥1.6
Adhesive strength of fiber combined products and concrete under faceup sticking condition MPA	≥2.5
Interbedded sheared length MPA	≥50	≥40
Volume content of the sheet(%)	≥65	≥55
Width(mm)	50/100	50/100
