Specifications
1.CE, ISO9001:20082.Air volume:150-1000 m3/h
3.Voltage/Frequency:220V/50Hz
4.Residential ventilators
5.High efficiency
Overview
KRV heat recovery unit also called energy recovery ventilator.
Function
· Remove the exhaust air(stable indoor air) and replace it with fresh outdoor air, improve the air quality.
· Double channels exchange the air flow separately, two air streams never mixed each other.
· Prevent harmful exposure to dangerous fumes and gases
· Eliminate humidity build-up that causes mold, mildew and damage to your home
· Makes your heating/cooling system run more efficiently
Characteristic
Energy Saving Crossflow heat exchanger core, recover the heat energy and humidity.
Application Range Air flow200-1000 m3/h, suitable for residence, villa, meeting room, office and so on.
Convenient Installation The heat recovery unit could be installed in ceiling,do not occupy indoor space and affect interior decoration, easy to design and installation.
Low Noise Optimized structure design, used sound-absorbing material and nonmetallic impeller, guaranteed the good static sound effect.
Complete-function Except the two-way air exchange,energy recovery,the bypass and LCD controller function are for selection.
Technology Parameter
| Model |
Air Volume (m3/h) |
Static Pressure (Pa) |
Rated Voltage |
Input Power (W) |
Summer | Winter |
Re. Net Weight (kg) |
|||||||||
|
Temperature Efficiency(%) |
Enthalpy Efficiency (%) |
Temperature Efficiency(%) |
Enthalpy Efficiency (%) |
|||||||||||||
| High | Low | High | Low | High | Low | High | Low | High | Low | High | Low | High | Low | |||
| KRV-1.5DT | 150 | 110 | 80 | 55 | 220V/50Hz | 60 | 40 | 75 | 77 | 60 | 63 | 75 | 77 | 67 | 70 | 24 |
| KRV-02DT | 200 | 150 | 75 | 65 | 220V/50Hz | 80 | 58 | 75 | 77 | 58 | 62 | 75 | 77 | 69 | 72 | 26 |
| KRV-03 DT | 300 | 250 | 85 | 75 | 220V/50Hz | 107 | 78 | 76 | 77 | 56 | 60 | 76 | 77 | 67 | 70 | 32 |
| KRV-04 DT | 400 | 350 | 90 | 80 | 220V/50Hz | 142 | 121 | 76 | 77 | 54 | 58 | 76 | 77 | 66 | 68 | 38 |
| KRV-05 DT | 500 | 450 | 110 | 95 | 220V/50Hz | 173 | 130 | 70 | 73 | 50 | 55 | 70 | 73 | 63 | 67 | 47 |
| KRV-06 DT | 600 | 500 | 100 | 90 | 220V/50Hz | 190 | 162 | 70 | 72 | 50 | 53 | 70 | 72 | 61 | 64 | 48 |
| KRV-08 DT | 800 | 700 | 120 | 100 | 220V/50Hz | 320 | 302 | 73 | 75 | 50 | 55 | 73 | 75 | 64 | 69 | 73 |
| KRV-10 DT | 1000 | 900 | 100 | 80 | 220V/50Hz | 410 | 360 | 74 | 77 | 54 | 58 | 74 | 77 | 66 | 70 | 92 |
Welcome to order our heat recovery unit.
