Specifications
1.Heat recovery Ceil ventilator2.Wind volume:600m3/h
3.Residual pressure:90Pa
4.Heat recovery efficiency:70%
KRV heat recovery ceil ventilator
Product description:
KRV series stand for heat recovery ceiling ventilator, the heat exchanger core is cross flow paper core, the major function is remove the exhaust air(stable indoor air) and replace it with fresh outdoor air, improve the air quality. It is suitable for installation in Home, office, meeting room. Not only exchanger fresh air, but also save energy.
Features:
1.Indoor and outdoor two-ways ventilation, equivalent exchanger of fresh air;
2.Low noise, corrosion and high tempreture resistant;
3.Paper core:high moisture-permeating rate, good air-tightness, tearing-resistance and aging-resistance
4.High heat recovery efficiency;
5.Sealed process stucture,easy to contral and maintain
Main parameter:
Model | Air Volume (m3/h) | Static Pressure (Pa) | Rated Voltage | Input Power (W) | Summer | Winter | Noise [dB(A)] | Dimension (mm) | Re. weight (kg) | ||||||||||
TemperatureEfficiency (%) | Enthalpy Efficiency (%) | Temperature Efficiency (%) | Enthalpy Efficiency (%) | ||||||||||||||||
High | Low | High | Low | High | Low | High | Low | High | Low | High | Low | High | Low | High | Low | ||||
KRV-05 DT | 500 | 450 | 110 | 95 | 220V/50Hz | 173 | 130 | 70 | 73 | 50 | 55 | 70 | 73 | 63 | 67 | 35 | 32 | 820×900×268 | 47 |
KRV-06 DT | 600 | 500 | 100 | 90 | 220V/50Hz | 190 | 162 | 70 | 72 | 50 | 53 | 70 | 72 | 61 | 64 | 35 | 33 | 830×910×288 | 48 |
KRV-08 DT | 800 | 700 | 120 | 100 | 220V/50Hz | 320 | 302 | 73 | 75 | 50 | 55 | 73 | 75 | 64 | 69 | 37 | 35 | 1110×880×388 | 73 |
KRV-10 DT | 1000 | 900 | 100 | 80 | 220V/50Hz | 410 | 360 | 74 | 77 | 54 | 58 | 74 | 77 | 66 | 70 | 38 | 36 | 1110×1135×388 | 92 |
Overview and ERC paper core:
KRV heat recovery ceil ventilator:
WELcome to visit Heat recovery ceil ventilator:
