HEU-S Outdoor Communication Cabinet with CE

Specifications

1.Outdoor Communication Cabinet
2.Cooling capacity:300W/k
3.Air volume:1500m3/h
4.CE and RoHs certification

Base station cooling ventilator machine



Introduction:

HEU-S Series Outdoor Communication Cabinet is specially design for mobile, telecom stations or computer room, etc, mainly used to eliminate the heat in the base station. The outdoor cold air after the purification, directly introduce into the equipment, then exchange the heat with exhaust air through the sensible heat recovery unit, expel heat from the equipment, so as to cool the equipment, reduce the consumption of energy, and not only provide an ideal temperature and humidity environment for the



Outdoor Communication Cabinet , but also separate the dust and moisture from the equipment, greatly extend the service life of electronics parts and improve the system reliability.



Features:



1.Energy Saving

It real-time control monitoring the inside and outside temperature ,when the outside temperature is lower to a certain extent, the equipment will begin to work, remove the inside heat to outside, so as to reduce the air-conditioner working time and save the energy.

2.Water And Dust Proof

Enclosed air circuit cooling system , completely isolate the inside and outside air, effectively avoid air contamination from outside.

Several Working Models and Standard RS485/RS232 Intelligent Control

3.DDGK function:

Setting the parameter for automatic protection, when the unit power outage, computer can record the parameter and outage information, after the power on, it will work again follow the status before the power outage ,it have the time delay function, to avoid power flash affect the unit or automatic trip .
4.Air-conditioner Troubleshooting

When base station air conditioner goes wrong,the equipment remove the inner heat to outside in time, make sure the electron devices working well.

5.Protection Warning Function and Stable performance

High quality accessories and less moving parts, so as to reduce the machine fault and easy to maintenance.



Aluminum foil core:



Performance Parameter:

Product Model(Middle-size) S20-S60
Parameter	Unit	HEU-S200	HEU-S300	HEU-S400	HEU-S500
Cooling capacity	W/K	200	300	400	500
Air Volume	M3/h	1000	1500	2000	2500
Static pressure	Pa	>50
Power	W	270	374	627	700
Voltage	V	AC:220V			AC:380V
Temp. Range	°C	-40 to 70°C  0-100%RH
Noise	dB(A)	50	52	54	55
Dimension	mm	1940x960x425	1650x980x485	1800x1250x505	1800x1250x605
Weight	Kg	86	102	132	168



 Workshop:

Base station cooling ventilator air exchange for CE:
