Specifications
1.Universal Modular Temperature Transmitter2.Connect thermal resistance (RTD), thermocouples (TC), resistance and voltage sign
Universal Modular Temperature Transmitter
Connect thermal resistance (RTD), thermocouples (TC), resistance and voltage signals
PC programmable sensor installed in the header of a Class B
For various input signals Universal PC programmable settings
Two-wire technology, 4 ... 20 mA analog output
The entire ambient temperature range of precision measurement
Sensor open or short circuit fault signal, pre-complying
NAMUR NE 43 standard
EMC, comply with NAMUR NE 21 standard, CE certification
UL certified components meet UL 3111-1 standards
GL German ship level certification
Explosion-proof Certification (Ex)
- ATEX Ex ia and 22 dust explosion (EN 50281-1)
- FM IS
- CSA IS
Electrical isolation
In the measurement process online using SETUP connector set
User-defined linearization
Characteristic curve adjustment
Output Simulation
| Head transmitter | ||
| Input | 1 x RTD, TC, Ohm, mV | |
| Output | 1 x analog 4...20 mA | |
| Auxiliary power supply | 8...35 V DC (standard-version) 8...30 V DC (Ex-version) | |
| Communication | PCP (pc-programmable) | |
| Installation | Terminal head form B | |
| Accuracy | (Pt100, -50...200 °C) <= 0,2 K (Pt100, -58...392 °F) <= 0,4 °F | |
| Galvanic isolation | yes | |
| Certification | UL Ex IS, NI GL marine approval GOST Ex i ATEX II1G EEx ia IIC T4/T5/T6 FM IS,NI,Class I,Div.1+2,Group ABCD CSA IS,NI,Class I,Div.1+2,Group ABCD ATEX II3G Ex nA II T4/T5/T6 ATEX II3D ATEX II1G EEx ia IIC T6, II3D ATEX II3G Ex nA II T6, II3D FM+CSA IS,NI,Class I,Div.1+2,Group ABC CSA General Purpose TIIS Ex ia IIC T4 TIIS Ex ia IIC T6 NEPSI Ex ia IIC T4-T6 NEPSI Ex nA II T4-T6 | |
