Omnigrad S TMT162R Pt100 Thermometer, Fieldtransmitter
Safe monitoring of process temperatures in challenging applications e. g. in the Oil & Gas industry
Product Overview
The robust thermometer is designed for use in demanding and safety relevant applications e.g. in the Chemical, Oil & Gas and Energy industry. The thermometer fulfills the corresponding safety requirements due to various certificates and tests. The use of a transmitter leads to higher accuracy and reliability in comparison to directly wired sensors.
Benefits
Dual compartment housing
Backlit display with large measured value, bargraph and fault condition indication
Galvanic isolation 2 kV (sensor input to the output)
Wide range of threaded thermowell connections available as standard
Replaceable measuring insert comprising a mineral insulated tube (SS 316L/1.4404)
Approvals for hazardous areas: Flameproof enclosure (Ex d), Intrinsic safety (Ex ia), Non-sparking (Ex nA)
Aluminum or stainless steel housing, degree of protection IP67, NEMA 4x
Field of application
Chemical/pharmaceutical industry
Petrochemical industry
Energy industry
Paper industry
General industrial applications
The TMT162R RTD assembly comprises a measuring insert (Pt100) and an electronic field transmitter with HART®, FOUNDATION Fieldbus™ or PROFIBUS® PA protocal.
Technical information
| Measuring Principle | Resistance Temperature Detector | |
| Characteristic / Application | US style modular temperature assembly for heavy duty applications suitable for hazardous areas threaded process connection to use with thermowell backlit display | |
| Terminal head | TMT162 - aluminium - field housing w. or w/o. display TMT162 - SS casting - field housing w. or w/o. display | |
| Thermowell / protection tube | to use with thermowell | |
| Insert / probe | mineral insulated (MI), flexible | |
| Max. immersion length on request | up to 30.000,00 mm (1.181,10'') | |
| Material protection tube/thermowell | 1.0460 (A105) 1.4401 (316) 1.4404 (316L) 1.4571 (316Ti) 1.4749 (~446) 1.7335 (13CrMo4-5; F-11) Alloy 600 (2.4816) Alloy C276 (2.4819) Duplex SAF 2205 (1.4462) Titan Gr2 (3.7035) | |
| Optional coating | Titan Gr2 (3.7035 ) Tantal PTFE Teflon PVDF | |
| Process connection | male thread: G1/2" NPT1/2" NPT3/4" union nut: NPT1/2" M24x1.5 | |
| Tip shape | straight | |
| Operating temperature range | PT 100: -200 °C ...600 °C (-328 °F ... 1.112 °F) | |
| Max. process pressure (static) | at 20 °C: 500 bar (7.252 psi) | |
| Accuracy | class A acc. to IEC 60751 1/3 DIN class B acc. to IEC 60751 | |
| Response time | depending on configuration t50 = 4 s t90 = 8 s | |
| Integration head transmitter | yes (4 … 20 mA; HART; PROFIBUS PA; FOUNDATION FIELDBUS) | |
| Ex - approvals | ATEX II 1G EEx ia IIC T4/T5/T6 ATEX II 2GD EEx d IIC T6 ATEX EEx d, EEx ia ATEX II 3G EEx nA IIC T4/T5/T6 ATEX II 1/2 GD EEx d IIC T6 ATEX II 1/2GD EEx ia IIC T4/T5/T6 | |
| Certification | Gost Metrology SIL | |
