SIEMENS SITRANS TH400 Temperature Head Transmitter
Product Discription
SITRANS TH400 is available either with PROFIBUS PA or FOUNDATION Fieldbus (FF). It is designed to support all common RTD, thermocouple, resistance and millivolt sensors. Setup is quick and easy with SIMATIC PDM(PA) or AMS and handheld communicator(FF). Due to its small size, the device allows flexible mounting options, even in a DIN Type B connection head.
Detail
Input | Resistance thermometers, Thermocouples, Resistance-type sensors, DC sources |
Output | PROFIBUS PA (variant), Foundation Fieldbus (variant) |
Benefits
Linearization of the sensor values
High accuracy across entire ambient temperature range
Reduces plant noise
Alarm signal for sensor break or short-circuit
Electromagnetic compatibility (EMC) according DIN EN 61326 and NE21
Saves expensive compensation cables with internal reference junction
Galvanic isolation for accuracy and safety in thermocouple applications
Single- or dual-point trim
Custom characteristic curve for application of non-standard sensors
Difference- and average-measurement
Measuring value of second sensor for redundancy
Extensive diagnostics
Simulation mode
Explosion-protection for US, Canada and Europe
Rugged design, fully potted electronics
