Explosion-proof Versions SAEx and SAREx
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Payment & Shipping
Payment Methods:
Port of Shipment:
Xi'an
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
Auma
Product Overview:
Explosion-proof versions SAEx and SAREx
Explosion-proof devices must be used in plants where potentially explosive atmospheres are likely to occur. These devices are designed so that they will not act as ignition source. Their constructive measures prevent the occurrence of ignition sparks or hot surfaces.
Certification is performed in close collaboration with national and international certification bodies.
Details:
- o Design features SAEx
- § Torque range from 10 Nm to 16,000 Nm
- § Output speeds from 4 to 90 rpm
- § Limit and torque sensing
- § Available with 3-ph AC motors
- § Handwheel for manual Operation
- o Design features SAREx
- § Torque range from 15 Nm to 4,000 Nm
- § Modulating torque range from 15 Nm to 1,600 Nm
- § Max. number of starts 1,200 c/h
- § Output speeds from 4 to 90 rpm
- § Limit and torque sensing
- § Available with 3-ph AC, 1-ph AC motors
- § Handwheel for manual operation
- o Ambient conditions
- § High enclosure protection
- § High quality corrosion protection
- § Wide ambient temperature ranges
- o Options
- § Intermediate position switches
- § Switches in tandem version
- § Remote position transmitter
- § Magnetic limit and torque Transmitter
- § Mechanical position indicator
- § Functional safety: Up to SIL 2 in selected configurations
- o Interfaces
-
§ Electrical connection via AUMA plug/socket connector
(optionally terminals) - § Cable entries in different versions
- § Output drive types according to ISO and DIN Standards
- o Approvals
-
§ Europe - ATEX
Ex de IIC/IIB T4 or T3
Ex d IIC/IIB T4 or T3 -
§ International level/Australia - IEC
Ex de IIC/IIB T4 or T3
Ex d IIC/IIB T4 or T3 -
§ USA - FM
FM CLASS I DIV 1 GROUPS (B), C, D T4 (T3C)
FM CLASS II DIV 1 GROUPS E, F, G T4 (T3C)
FM CLASS III DIV 1 T4 (T3) -
§ Russia - ROSTECHNADSOR/EAC (TR-CU)
1ExdeIICT4/T3
1ExdIICT4/T3
