Bourdon Tube Pressure Gauge Type 111.11PM Panel Mount Gauge Standard Series
- 10000 Piece / Pieces per Month
- Xi'an
- Credit Card
You May Like
-
Bourdon Tube Pressure Gauge Type 111.12, ABS Plastic or Painted Steel Case
-
Bourdon Tube Pressure Gauge, Type 111.11 Compressed Gas Regulator Gauge
-
Bourdon Tube Pressure Gauge Type 111.10SP Sprinkler Gauge Standard Series
-
Bourdon Tube Pressure Gauge Type 111.10R Refrigeration Gauge Standard Series
-
Bourdon Tube Pressure Gauge Type 111.10
-
Bourdon Tube Pressure Gauge Type 111.25CT Contractor Gauge Standard Series
Product Details
| Place of Origin | Germany | Model Number | 111.11PM |
Product Description
Bourdon Tube Pressure Gauge Type 111.11PM Panel Mount Gauge Standard Series
Applications
- Compressed gas regulation
- HVAC and recovery systems
- Suitable for all media that will not obstruct the pressure system or attack copper alloy parts
Special features
- Durable black ABS case
- Twist-lock window
- Reliable and economical
Standard Features
Design
ASME B40.100
Sizes
2½” (68 mm)
Accuracy class
± 3/2/3% of span (ASME B40.100 Grade B)
Ranges
Vacuum / Compound to 200 psi
Pressure from 15 psi to 6,000 psi
or other equivalent units of pressure or vacuum
Working pressure
Steady: 3/4 of full scale value
Fluctuating: 2/3 of full scale value
Short time:full scale value
Operating temperature
Ambient: -40°F to 140°F (-40°C to 60°C)
Media: 140°F (+60°C) maximum
Temperature error
Additional error when temperature changes from referencetemperature of 68°F (20°C) +0.4% for every 18°F (10°C)rising or falling. Percentage of span.
Pressure connection
Material: copper-alloy
1/8“ or 1/4“ NPT center back mount (CBM)
