Proline Promag L 400 Electromagnetic flowmeter
The flowmeter with integrated web server and a weight-optimized sensor
Product Overview
Promag L is the versatile standard sensor designed for the water industry with a lap-joint flange concept for flexible installation independent of the orientation of the pipe flange pitch diameter. Combined with Proline 400, the transmitter for optimized measurement of water and wastewater, Promag L 400 will be the preferred solution for all standard applications in this industry. Promag L 400 also offers an integrated web server. Integrated verification with Heartbeat Technology.
Benefits
Reduced installation costs – flexible mounting by one-of-a-kind lap-joint flange concept (DN < 350/14")
Energy-saving flow measurement – no pressure loss due to cross-section constriction
Maintenance-free – no moving parts
Safe operation – no need to open the device due to display with touch control, background lighting
Time-saving local operation without additional software and hardware – integrated web server
Integrated verification – Heartbeat Technology™
Field of application
The measuring principle is virtually independent of pressure, density, temperature and viscosity
Fully suitable for standard applications in the water and wastewater industry.
Device properties
Up to 30% less sensor weight
Nominal diameter: DN 25 to 2400 (1 to 90")
Maximum reduced installation length to DVGW/ISO
Transmitter housing made of durable polycarbonate or aluminium
Same housing concept for compact/remote version
Integrated data logger: measured values monitoring
Technical information
| Measuring Principle | Electromagnetic | |
| Product headline | The flowmeter with integrated web server and a weight-optimized sensor. Fully suitable for standard applications in the water and wastewater industry. | |
| Sensor features | Reduced installation costs – flexible mounting by one-of-a-kind lap-joint flange concept (DN < 350/14"). Energy-saving flow measurement – no pressure loss due to cross-section constriction. Maintenance-free – no moving parts. Up to 30 % less sensor weight. Nominal diameter: DN 25 to 2400 (2 to 90"). | |
| Transmitter features | Safe operation – no need to open the device due to display with touch control, background lighting. Time-saving local operation without additional software and hardware – integrated web server. Integrated verification – Heartbeat Technology™. Transmitter housing made of durable polycarbonate or aluminium. Same housing concept for compact/remote version. | |
| Nominal diameter range | Lap joint flange, lap joint flange, stamped plate: DN 25 to 300 (1 to 12") Fixed flange: DN 350 to 2400 (14 to 90") | |
| Wetted materials | Liner: PTFE; Polyurethane; Hard rubber Electrodes: 1.4435 (316L); Alloy C22, 2.4602 (UNS N06022) | |
| Measured variables | Volume flow, conductivity, mass flow | |
| Max. measured error | Volume flow (standard): ±0.5 % o.r. ± 1 mm/s (0.04 in/s) Volume flow (option): ±0.2 % o.r. ± 2 mm/s (0.08 in/s) | |
| Measuring range | 9 dm³/min to 162 000 m³/h (2.5 gal/min to 1030 Mgal/d) | |
| Max. process pressure | PN 16, Class 150 | |
| Medium temperature range | Liner material hard rubber: 0 to +80 °C (+32 to +176 °F) Liner material polyurethane: –20 to +50 °C (–4 to +122 °F) Liner material PTFE: –20 to +90 °C (–4 to +194 °F) | |
| Ambient temperature range | Flange material carbon steel: –10 to +60 °C (+14 to +140 °F) Flange material stainless steel: –40 to +60 °C (–40 to +140 °F) | |
| Sensor housing material | DN 25 to 300 (1 to 12"): AlSi10Mg, coated DN 350 to 2400 (14 to 90"): Carbon steel with protective varnish Sensor connection housing: AlSi10Mg, coated | |
| Transmitter housing material | Polycarbonat; AlSi10Mg, coated | |
| Degree of protection | Compact version: IP66/67, type 4X enclosure Sensor remote version (standard): IP66/67, type 4X enclosure Sensor remote version (option): IP68, type 6P enclosure Transmitter remote version: IP66/67, Type 4X enclosure | |
| Display/Operation | 4-line backlit display with touch control (operation from outside) Configuration via local display, web browser and operating tools possible | |
| Outputs | 3 ouputs: 0-20 mA/4-20 mA HART (active) Pulse/frequency/switch output (passive) Pulse/frequency output (passive) Switch output (passive) | |
| Inputs | Status input | |
| Digital communication | HART, PROFIBUS DP, EtherNet/IP, Modbus RS485 | |
| Power supply | AC 100 to 240 V / AC/DC 24 V | |
| Hazardous area approvals | cCSAus | |
| Other approvals and certificates | Calibration performed on accredited calibration facilities (acc. to ISO/IEC 17025), NAMUR Drinking water approval: ACS, KTW/W270, NSF 61, WRAS BS 6920 | |
