Help Center1X4 Fused Fiber Splitter(Coupler)
Related Products
-
3x3 Fused Fiber Coupler(Splitter)US$ 4 - 15MOQ: 10 Pieces -
1x2 FBT Optical Splitter(Coupler)US$ 4 - 15MOQ: 10 Pieces
-
1x2 Singlemode Optical Splitter(Coupler)US$ 4 - 15MOQ: 10 Pieces
-
4x4 FBT Optical Coupler(Splitter)US$ 4 - 15MOQ: 10 Pieces
-
Single Mode Fiber Optic Splitter CouplerUS$ 4 - 15MOQ: 10 Pieces
Specifications
Fused Fiber Splitter1 Low insertion loss
2 Low polarization dependence
3 High optical return loss
4 Better uniformit
1X4 Fused Fiber Splitter(Coupler)
Fiber optic splitter, also called optical splitter, fiber optic coupler, is a device applied in optical fiber systems with one or more input fibers and one or several output fibers. There are mainly two types of optical splitters. One is fused splitter (FTB),The other is Planar Lightwave Circuits (PLC Splitter).For the fused optical splitter, It can be divided into different ratios. such as 50/50 if the split is even, or 80/20 if 80% of the signal goes to one side and only 20% to the other. Planar Lightwave Circuits (PLC Splitter) can not work with different ratio rather than it provide a accurate splitting in high-density output (like 8,16,32,64 outputs). However, The most common type of fiber optic splitter splits the output evenly, which is coming out with the same output of light signals. As a result of its great function, Optical splitter is a very important part in passive optic networks (PON).
1X4 Fused Fiber Splitter(Coupler)
HIGH QUALITY 1X4 Fused Fiber Splitter(Coupler)
1 Low insertion loss & excess loss
2 Low polarization dependence
3 High optical return loss
4 Better uniformity
5 Environmental Stability and Reliability
6 Small package size
1X4 Fused Fiber Splitter(Coupler) Specifications
| Type | 1x4 | 1x4 | 1x4 | ||||
| Operating wavelength(nm) | 1310 or 1550 | 1310/1550 | 1310/1490/1550 | ||||
| Operating bandwidth(nm) | ±20 | ±40 | |||||
| Grade | P | A | P | A | P | A | |
| Typical excess loss(dB) | 0.4 | 0.5 | 0.5 | 0.7 | 0.5 | 0.7 | |
| Insertion loss (dB) | ≤6.8 | ≤7.0 | ≤7.0 | ≤7.2 | ≤7.0 | ≤7.2 | |
| PDL (dB) | ≤0.25 | ≤0.25 | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.3 | |
| Uniformity(dB) | 0.6~0.8 | 0.8~1.2 | |||||
| Directivity(dB) | ≥55 | ||||||
| Operating temperature(°C) | -40 ~ +85 | ||||||
| dimension Size |
250µm bare fiber | 3.0mm×54mm | |||||
| 900µm loose tube 0.9 | 4.0mm×65mm | ||||||
1X4 Fused Fiber Splitter(Coupler) Applications
1 FTTH, LAN, PON & Optical CATV
2 Local ring net
3 Optical fiber communication system
4 Optical fiber test equipment
5 Optical fiber sensor
1X4 Fused Fiber Splitter(Coupler) Image1
1X4 Fused Fiber Splitter(Coupler) Image2
We Supply all kinds of FBT Splitter and PLC Splitter.
Facory Coner:
