Specifications
1.Good Performance of film2.flat and smooth. Dust is easy to be removed
3.Good corrosion resistance
4.good impact strength
Welcome to Locwid Company
1. Product information
FRP gel coat flat sheet is solidified and composited by gel coat, polymer resin and glass fiber. It is a new eco-friendly product developed by our company .It can be widely used in making high grade panels of vehicles, refrigerated vans,purification,medical treatment and food engineering etc. It can instead of colored steel plate, stainless steel plate, aluminum plate and PVC plate etc. With good features of high strength, hardness, smooth surface, wear-resistance, corrosion resistance, aging resistance, cleanliness and bacteria resistance. etc. The thickness can be adjusted easily(1.0mm~5.0mm), and packaged in rolls and sizing.
2. Performance
<1> Smooth surface, light weight, anti-aging, anti-corrosion
<2> suitable for acid and alkali environment.
<3>Always used on truck body, container, inside board of the refrigerator, ceiling panels, commercial, civil construction and public facilities interior walls and ceiling. Modified car, or other special purpose transport outer panels etc.
3. Technical parameter
| No | Item | Technical data | Value | Result | Test method |
| 1 | Oxygen index (%) | ≥27 | 27.2 | pass | GB/T 2406-1993 |
| 2 | Horizontal Burning , (class) | FH-1 | FH-1 | pass | GB/T 2408-1996 |
| 3 | Vertical Burning ,(class) | FV-1 | FV-1 | pass | GB/T 2408-1996 |
| 4 | Tensile strength (MPa) | / | pass | GB/T 1447-2005 | |
| 5 | Flexural strength(MPa) | / | 263 | GB/T 1447-2005 | |
| 6 | Low temperature impaction | -40°C×1h | 10/0 pass | GB/T 8814-2004 | |
| 7 | transmittance % | / | 86.8 | GB/T 2410-1980 | |
| 8 | Water absorption % | / | 0.38 | GB/T 17657-1999 | |
| 9 | Barcol hardness | / | 51 | GB/T 3854-2005 | |
| 10 | Distortion temperature(1.81Mpa) | / | Above 260 | GB/T 1634-2004 | |
| 11 | Heat conductivity 25°C W/(m•k) | / | 0.648 | GB/T 10297-1998 | |
| 12 | Modulus of elasticity in static bending | Gpa | 6.1 | GB/T 1447-2005 | |
| 13 | Acid resistance | / | No change in surface | Refer to GB/T 4218-1984 | |
| 14 | Alkali resistance | / | No change in surface | Refer to GB/T 4218-1984 | |
| 15 | Loading performance,mm | ≤30 | 6 | pass | JC/T 562-1994 |
4. Application
