China 6x31WS Ungalvanized Steel Wire Rope

FOB Price

US$ 1,075 - 1,133 / Metric Ton

5 Metric Tons(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Steel Grade	60#65#70#	Standard	AISI, ASTM, BS, DIN, GB, JIS
Wire Gauge	10~40mm	Place of Origin	Hebei, China
Type	Other, round	Application	Other, hauling in machinery, architectural, tugging, shipping fishery,etc
Alloy Or Not	Non-alloy	Model Number	6x31WS+FC/6X31WS+IWR/6X31WS+IWS
Brand Name	JINBAO

Executive standard:GB8918-2006 or according to requirement of customers
Specifications:10mm~40mm

Product Description

China 6x31WS ungalvanized steel wire rope

It is mainly used for hauling in machinery, architectural, tugging, shipping fishery, lifting of goods.

Structure: 6x31WS+FC/6X31WS+IWR/6X31WS+IWS

Executive standard: GB8918-2006 BS302 RR-W-410E ASTM A 1023/ADIN3051 JIS G 3525 EN 12385-4:2002

Specifications:Φ10mm~Φ40mm

Tensile strenght:1470~1870Mpa

Minimum breaking force
Group	Category	weight coefficient K			K₂/K_1n	K₂/K_1p	Minimum breaking force coefficient K′		K′₂ K′₁
		natural fiber core	synthetic fiber core	steel core			fiber core	steel core
		K_1n	K_1p	K₂			K′₁	K′₂
		kg/100m·mm²					K′₁	K′₂
1	1*7	-		0.522	-	-	-	0.54	-
	1*19	-		0.507	-	-	-	0.53	-
	1*37	-		0.501	-	-	-	0.49	-
2	6*7	0.351	0.344	0.387	1.1	1.12	0.332	0.359	1.08
3 4	619(a) 637(a)	0.38	0.371	0.418	1.1	1.13	0.33	0.356	1.08
3	6*19(b)	0.351	0.344	0.4	1.14	1.16	0.307	0.359	1.08
4	6*37(b)	0.346	0.337	0.4	1.16	1.19	0.295	0.356	1.08
5	6*61	0.361	0.354	0.398	1.1	1.12	0.283	0.332	1.08
6 7	819 837	0.357	0.344	0.435	1.22	1.26	0.293	0.319	1.18
8 9	187 1819	0.39		0.43	1.1	1.1	0.31	0.328	1.06
10	34*7	0.39		0.43	1.1	1.1	0.308	0.318	1.03
11	35W*7	-		0.46	-	-	-	0.36	-
12	6*12	0.251	0.231	-	-	-	0.209	-	-
13	6*24	0.318	0.304	-	-	-	0.28	-	-
14	6*15	0.2	0.185	-	-	-	0.18	-	-
15 16	419 437	0.41		-	-	-	0.36	-	-
