Steel Wire Rope for Conveyer Belt

Name: Steel Wire Rope for Conveyer Belt
Brand: JINBAO
SKU: 141917986
Availability: InStock

US$ 700 - 900 MOQ: 5 Metric Tons

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

JINBAO

Model Number:

2-12mm

Hebei Jinbao Steel Wire Rope Company Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name JINBAO

Model Number 2-12mm

Specifications

Dia.:2-12mm
Tensilestrength:1570-1860Mpa
Use:Framework-reinforcing material.

It is mainly used for framework-reinforcing material.

Dia/ (mm)	Weight/ (kg/100m)			Steel Wire Rope Tensile Strength/Mpa
				1570		1670		1770		1870
				Steel Wire Breaking Force(Min)/kN
	Nature Firbre Core	Synthetic Fibre Core	Steel Core	Fibre Core	Steel Core	Fibre Core	Steel Core	Fibre Core	Steel Core	Fibre Core	Steel Core
1.8	1.14	1.11	1.25	1.69	1.83	1.8	1.94	1.9	2.06	2.01	2.18
2	1.4	1.38	1.55	2.08	2.25	2.22	2.4	2.35	2.54	2.48	2.69
3	3.16	3.1	3.48	4.69	5.07	4.99	5.4	5.29	5.72	5.59	6.04
4	5.62	5.5	6.19	8.34	9.02	8.87	9.59	9.4	10.2	9.93	10.7
5	8.78	8.6	9.68	13	14.1	13.9	15	14.7	15.9	15.5	16.8
6	12.6	12.4	13.9	18.8	20.3	20	21.6	21.2	22.9	22.4	24.2
7	17.2	16.9	19	25.5	27.6	27.2	29.4	28.8	31.1	30.4	32.9
8	22.5	22	24.8	33.4	36.1	35.5	38.4	37.6	40.7	39.7	43
9	28.4	27.9	31.3	42.2	45.7	44.9	48.6	47.6	51.5	50.3	54.4
10	35.1	34.4	38.7	52.1	56.4	55.4	60	58.8	63.5	62.1	67.1
11	42.5	41.6	46.8	63.1	68.2	67.1	72.5	71.1	76.9	75.1	81.2
12	50.5	49.5	55.7	75.1	81.2	79.8	86.3	84.6	91.5	89.4	96.7
13	59.3	58.1	65.4	88.1	95.3	93.7	101	99.3	107	105	113
14	68.8	67.4	75.9	102	110	109	118	115	125	122	132
16	89.9	88.1	99.1	133	144	142	153	150	163	159	172
18	114	111	125	169	183	180	194	190	206	201	218
20	140	138	155	208	225	222	240	235	254	248	269
22	170	166	187	252	273	268	290	284	308	300	325
24	202	198	223	300	325	319	345	338	366	358	387
26	237	233	262	352	381	375	405	397	430	420	454
28	275	270	303	409	442	435	470	461	498	487	526
30	316	310	348	469	507	499	540	529	572	559	604
32	359	352	396	534	577	568	614	602	651	636	687
34	406	398	447	603	652	641	693	679	735	718	776
36	455	446	502	676	730	719	777	762	824	805	870
