US$ 656 - 866 MOQ: 3 Tons
Key Specifications
Get Latest Price
Standard:
AISI, ASTM, BS, DIN, GB, JIS
Grade:
55Q,Q235,45Mn,50Mn
Rail Heigth:
63.00mm-114.00mm
Contact Supplier Request Quote Chat Now
Fujian Fenan Aluminium Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
fuzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Standard AISI, ASTM, BS, DIN, GB, JIS
Grade 55Q,Q235,45Mn,50Mn
Rail Heigth 63.00mm-114.00mm
Bottom Width 63.00mm-114.00mm
Web Thickness 5.90-17.00mm
Head Width 25.00-68.00mm
Length as your requirement
Place of Origin Fujian, China
Brand Name FENAN
Model Number Rail Steel Materials
Type Heavy Rail
Application Railway Rail
Weight 8.94KG/M2-51.514KG/M2
Secondary Or Not Non-secondary
Bolt Hole Diameter 22mm 24mm

Specifications

Rail Steel Materials
steel rail in china
Railway Rail, Railroad Steel Rail, Railway Track
Standard: BS, DIN, GB, JIS
Grade

Product: Rail Steel Materials



key words:  Rail Steel Materials



Name of Products:Steel Rail
Specification(KGS/M):9kg,12Kg,15Kg,18kg,22Kg,24Kg,30Kg



                                                                                                    THE LIST OF Steel Rail

Name of Commodity Specificaton Materials   (Steel Grade) Standard of Products Theory Weight (kgs/M) Length of Dimension     (M) Packed In Bundle With Iron Wire (pcs/bundle)
Light Rail 4kgs/m Q235 Q/YYG001-2008 4kgs/m 6,8,9,10 75
8kgs/m Q235 Q/YYG001-2008 8.42kgs/m 55
12kgs/m Q235 GB11264-89 12.2kgs/m 36
15kgs/m Q235/55Q/50Q GB11264-89 15.2kgs/m 28
18kgs/m Q235/55Q/50Q YB222-63 18.06kgs/m 21
22kgs/m Q235/55Q/50Q GB11264-89 22.3kgs/m 21
24kgs/m Q235/55Q/50Q Q/YYG001-2008 24.46kgs/m 21
30kgs/m Q235/55Q/50Q GB11264-89 30.1kgs/m 15
Heavy Rail 38kgs/m U71Mn/U71 GB2585-81 Q/YYG002-2008 38.733kgs/M 12,12.5 10
43kg/m U71Mn/U71 GB2585-81 Q/YYG002-2008 44.653kgs/M 10
50kgs/m U71Mn/U71 GB2585-81 Q/YYG002-2008 51.514kgs/M 10
  45/50Mn Q/YYG002-2008 31/34/36/39/41kgs/M 12,12.5 10
Crane Rail QU70 U71Mn YB/T5055-93 52.8kgs/m 12,12.5 10
QU80 YB/T5055-93 63.69kgs/m 10
QU100 YB/T5055-93 88.96kgs/m 5
QU120 YB/T5055-93 118.1kgs/m 5
I-beam of Hot-Rolled Section Steel for Mine 9# 20MnK/ Q235 YB/T5047-2000 17.69kgs/m 8,9,10 28
11# YB/T5047-2000 26.05kgs/m 18
12# YB/T5047-2000 31.18kgs/m 15
Hot-Rolled U-Beam Steel for Mine Timbering  25U 20MnK/ Q275 GB4697-1991 /Q/YYG006-2008 24.95kgs/m 8,9,10,12 15
29U GB4697-1991 29kgs/m 15
36U Q/YYG006-2008 35.87kgs/m 15

Name of Commodity Specificaton Equal to rails Materials Standard of Products Theory Weight (kgs/set) Length of Dimension  (mm) Packed In Bundle With Iron Wire    (set)
Fish Plate 4/9kgs/M Q235B or … GB11265-89 0.80 ≈270-385 50
1.00
12kgs/M GB11265-89 1.10 ≈409 50
1.30-1.50
15/18kgs/m GB11265-89 1.80-2.00 ≈372-409 25
2.20-2.50
2.80-3.00
22/24kgs/M GB11265-89 3.30-3.50 ≈426-510 20
3.80-4.00
4.20-4.50
30kgs/m GB11265-89 5.50-7.50 ≈561 10
8.20-8.50
38/43/50kgs/m GB185-63 24-30 ≈790 1



Rail Steel  size

Light rail

Size

Kg/m

Height (mm)

Bottom width

(mm)

Head width

(mm)

Middle thickness

(mm)

Length

(m)

Weight (kg/m)

Standard

5

50

44

22

4.5

5-10

5.03

YB

8

65

54

25

7

5-10

8.42

YB

11

80.5

66

32

7

6-10

11.2

YB

15

91

76

37

7

6-12

14.72

YB

18

90

80

40

10

7-12

18.06

YB

24

107

92

51

10.9

7-12

24.46

YB

9

63.50

63.50

32.10

5.90

5-7

8.94

GB

12

69.85

69.85

38.10

7.54

6-10

12.20

GB

15

79.37

79.37

42.86

8.33

6-10

15.20

GB

22

93.66

93.66

50.80

10.72

7-10

22.30

GB

30

107.95

107.95

60.33

12.30

7-10

30.10

GB

Heavy rail

Size

Kg/m

Height (mm)

Bottom width

(mm)

Head width

(mm)

Middle thickness

(mm)

Length

(m)

Weight (kg/m)

Standard

33

120

110

60

12.5

12.5

33.286

GB

38

134

114

68

13

12.5-25

38.733

GB

43

140

114

70

14.5

12.5-25

44.653

GB

50

152

132

70

15.5

12.5-25

51.514

GB

60

176

150

73

16.5

9-12.5,25



GB

Crane rail

Size

Height (mm)

Bottom width

(mm)

Head width

(mm)

Middle thickness

(mm)

Length

(m)

Weight (kg/m)

Standard

QU70

120

120

70

28

12

52.8

GB

QU80

130

130

80

32

12

81.13

GB

QU100

150

150

100

38

12

113.32

GB

QU120

170

170

120

44

12

150.44

GB





























































Specifications:



Steel Hand Rail
1.High quality & Good price
2.Customized service
3.Easy installation

4.Free design



Steel HandRails:



Balustrade specification:

Component

Alternative

Material

Alternative

Specification

Alternative

Surface

Finish

Handrail

for

Balustrade

s.s.304;

s.s.316;

PVC;

Solid wood

Dia.50mm;

Dia.38mm

Brushed;

Mirror

s.s.304;

s.s.316

10*60mm;

30*60mm

s.s.304;

s.s.316

50*50mm

Glass

for

Railing

Tempered

8mm;

10mm;

12mm;

15mm

clear;

frosted;

tinted;

super white

Post

s.s.304;

s.s.316

as per picture

Brushed;

Mirror

S.s.

Tube/Rod

s.s.304;

s.s.316

8mm;

10mm;

12mm

Brushed;

Mirror

Wire/Cable

s.s.304;

s.s.316

4mm-6mm



Design



European standards

or

Australian Standards





Needed information for Balustrade quotation:

a)       Pls tell us which product you like.

b)      Pls tell us how many meters of balustrade you need.

c)       If you have any special requirements, pls also tell us.



Design(building codes)

Generally, we design as per Australian Building Codes, or European Standards, but we can also design as per customer’s requirements.



Packing

The glass will be packed in strong totally-enclosed wooden crates, no glass can be seen.

Stair stringers also will be protected in wooden crates. Cartons are used to pack steel parts. Some long tubes or rods are wrapped by woven bags.



Installation Tools

To save your time and cost, all of our products are designed to be installed by screws, NO NEED WELDING.

For the convenience of installation, we will provide detailed drawing and photos for guidance. We also will give labels to each tiny fitting.





Difference of ss304 and ss316

First s.s.316 and s.s.304 looks same from appearance. But, ss 316 has more nickel content than ss 304, which improves its corrosion resistance, especially ss 316 is more resistance to pitting corrosion by chloride ion. Generally, ss316 is used for outdoor of sea side building. If it is for other places, s.s.304 is good enough.



Factory:

Rail Steel Materials





Certificates:



Rail Steel Materials

Rail Steel MaterialsRail Steel MaterialsRail Steel Materials

Choose FENAN, you are choosing a better life! Better quality products, more professional design, best sales service! Your satisfaction is our greatest achievement.

if you are interesting in,pls contact: Ms. Sarah (skype: sarahshang88)
