Specifications
Aluminum Profile1.alloy:6061,6063,6005 T5,T6
2.mill finish, anodized, powder coated, wood color
FENAN Window and Door Corner Aluminum Profile
| Our main Products | ||||||
| 1.Material:Aluminum Alloy 6063 6005 | ||||||
| 2.Temper avaiable: T5, T6 | ||||||
| 3.Surfaceavaiable:Mill finish,Anodize,Powder Coated,Wooden finish | ||||||
| 4.Certificate: ISO9001/ISO14001,CHSAS 18001 | ||||||
| 5.Thickness :above0.8mm | ||||||
| 6.length:according to your requirements | ||||||
| 7.we have 24years experience,had many kinds of the moulds ourselves. | ||||||
| 8.future preccessing :cutting ,drill,de-beur,asseble | ||||||
| 9.packing can be done as your requirements(our normal packing for the length less 3.5m ,is the carton box +pallet ,and for the long profile use the Epe Foam+ kraft paper derectly for the FCL shipment. |
Primary Technical Data
Chemical composition
Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Impurity | Al |
6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.90 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
6061 | 0.4-0.8 | 0.70 | 0.15-0.40 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.15 | Rest |
6005 | 0.6-0.9 | 0.35 | <0.1 | <0.1 | 0.40-0.6 | <0.1 | <0.1 | <0.1 | <0.15 | Rest |
Mechanical property
Alloy | Condition | Tensile strength | Yield strength | Elongation | Vickers hardness |
6061 | T6 | >265Mpa | >245Mpa | >8% |
|
6063 | T5 | >160Mpa | >110Mpa | >8% | HV>58 HW>8 |
T6 | >205Mpa | >180Mpa | >8% |
|
Colored anodized profile
Grade | Thickness of film | Hole scaling quality of oxide layer | |
Average thickness | Local thickness | P. Cr acid-erosion weight less method | |
AA10 | >10um | >8mm | <30 mg/d m2 |
AA15 | >15um | >12um | |
Electrophoretic coating profiles
Grade | Anodic oxide film | Thickness of paint film | Thickness of complex film | Film hardness | |||||
Average thickness | Local thickness | ||||||||
A | >10um | >8um | >12um | >21um | >3um | ||||
B | >10um | >8um | >7um | >17um | >3um | ||||
Powder coating & wooden-grained profile
Coating thickness | Coating impress rigidity | Adhesive force of coating layer |
40-120um | Indentation hardness>80 | 0 grade |
Thermal-break profile
type | Characteristic value of longitudinal shear strength Tc | Characteristic value of transverse strength Qc |
Inserting | >24N/mm | >24N/mm |
Pouring | >24N/mm | >24N/mm |
About Us
We are ISO certified manufacturer in Fuzhou, China, specialized in R & D, marketing and production of various aluminum extrusion , doors and windows, curtain wall and stainless steel products. Established in 1988, FENAN Group now occupy 140000 sq. meters, housing 18 extrusion lines with more than 700 workers, Annual output reach 35000 tons.
What kind of products and service we can provide
· Aluminum profile for doors, windows, fence, screen, curtain wall, handrail, partition, wardrobe, etc
· Industrial modular aluminum profile, such as solar panel frame, exhibit shelf, LED frame, production line, auto parts, etc;
· Doors and Windows System, include sliding door, side hung window, tilt and turn window, etc
· Deep Processing Ability for aluminum and S/S products: Fabrication, Drill hole, milling, de-burr, chamfer, stretch bending, welding and so on;
· Engineering design and Consult
Your any inquiry on our products will be replied by our skilled sales in 24 hours.
FENAN Group,Your One-Stop-Factory for aluminum products!
