Help CenterHZS75 Concrete Batching Plant
Related Products
Specifications
One concrete mixing plant is made up of mixing system, batching system, electric control system, storage silo, powder conveyer s
Concrete mixing plants series HZS are second-order automatic or semi-automatic concrete complete sets of equipments. One concrete mixing plant is made up of mixing system, batching system, electric control system, storage silo, powder conveyer screw, etc. They can be used for large and medium-sized building sites, prefabricated factories, concrete manufacturers, etc. They can be divided into simple (centralized control) and standard according
Products features
The mixing console is double-horizontal-shaft forced type, good mixing quality and efficient.
Combined structure. It is easy to be moved. Complete engine set installation
The mortar aggregate, powder, liquid aggregate are measured by electronic balance, so the batching precision is high.
The electrical control system adopted imported electronic components. They have reliable performance. It is convenient to operate.
to different electric control system.
No. |
Commodity name |
quatity |
note |
|
01 |
Control system of electricity |
Strong electricity |
1 |
With dedicated microcomputer control from ADVANTECH , Taiwan ; 19`` SAMSUNG/PHILIPS LCDand EPSON prienter; main electricity with Schneider- France |
|
Electric Control system | ||||
02 |
Mixing console |
1 |
Js1500 dual-axial mixing; Double main reducer, dual cylinder discharging.The shaft seal protection, multiple effectively eliminate leak slurry phenomenon |
|
03 |
Feedng system of aggregate |
1 |
Feeding syetem with Climb bucket;high efficient;easy to overhauling;With a full stop without limit, completely eradicate hopper protection device header phenomenon. |
|
04 |
Batching plant |
1 |
Pld2400A electronic batching plant ; discharging with pneumatic;; Accurate measurement, high production efficiency. |
|
05 |
Measuring system of powder
|
1 |
Measuring system with electronic balance Anticorrosion unloading pump. |
|
06 |
Measuring system of cement |
1 |
Measuring system with electronic balance,Pneumatic butterfly discharging. |
|
07 |
Measuring system of water |
1 |
Measuring system with electronic balance; Discharge pump. |
|
08 |
filler bin |
2 |
100t filler bin ,With Silo material level instrument, warehouse top precipitator, unloading valve disc, current mouth, blowing arch breaker;Main component is Scutti from Italian. Cement storehouse use flake structure, simple and convenient maintenance and assembly. |
|
09 |
screw conveyer LSY219/9M |
2 |
With Scutti from Italian ,Expressway cement screw conveyor |
|
10 |
Admixtures box |
1 |
With mixing and cycling function. |
|
11 |
Stent |
1 |
With Steel structure type mixing platform; Discharging weight 3.8m. |
|
12 |
Control room |
1 |
Gree and haier 1 horse air conditioning. |
|
13 |
Pneumatic system |
1 |
air compressor and Related gas, gas box. |
|
14 |
cable |
1 |
Contain relevant signal and power cable, pipeline. |
|
