Specifications
Steel structure prefabricated container house1.easy to move and install
2.long lifspan
st & time saving
4.ISO9001:2000
China low cost steel structure prefabricated container house
The standard container for various purposes is suitable for international container transport. It is of appropriate external dimensions and has connections for lifting and fixing or compounding. The container is designed as a light construction consisting of floor and roof frames and corner profiles. The construction enables compounding of individual containers in longitudinal and transverse directions without limits. It also enables compounding of containers in 2 floors in height (ground floor + first floor), or in 3 floors in height for warehousing of these containers (ground floor + 2 floor).
Steel structure prefabricated container house specifications:
Name | Type | Material | Size |
Wall Panel
| 1.wall panel with steel sheet on both external and internal sides
2. wall panel with steel sheet on external side and chipboard on internal side
|
2.Mineral Wool 3.PU
| Width:1145mm
Thickness : Customizable (rang from 60mm to 100mm)
|
Door
| 1.Steel Door 2.Aluminum Door 3.Aluminum Alloy Door 4.PVC Door 5.Fireproof Door | 1.Honeycomb Paperboard 2.Mineral Wool 3.PU
| Ordinary Size: 950*1995mm 870*2040
Customizable |
Window
|
1.Sliding Window 2.Tilt & Turn Window |
1.PVC 2.Aluminum Alloy
| Ordinary Size: 945 x 1,200 mm 800 x 1,100 mm
Customizable
|
Electrical Installation
| Switch and Socket
| 1. CE Standard 2. Australia Standard 3. UL Standard |
Steel structure prefabricated container house advantages:
1) Easy to assemble and disassemble with simple and common tools.
2) Heat and sound insulation, water and fire proofing.
3) Attractive appearance The whole structure is handsome with adopting the color coated steel sheet. 4) Environmentally friendly and economical . Reasonable design makes it reusable. The reusable character makes it environmentally friendly and economical.
5) Cost efficient A grade materials, reasonable price, all investment low requirements for base and short completion time make it cost efficient.
6) Light weight, convenient for shipment and transportation.
7) the components of the house can be used repeatedly
8) Beautiful appearance, virious colors and shapes for outer and inner roof panel and wall panel.
9) Various designs available, customized designs acceptable.
10) Wide range of application, could be used as offices, command posts, sentry boxes, dormitories, shops,Kiosks and so on.
11) if you need ,we can provide the service of installation by extra
Steel structure prefabricated container house dimensions:
10’: 3027x2435x2591/2791mm
20’: 6055x2435x2591/2791mm
30’: 9000x2435x2591/2791mm
40’: 12192x2435x2591/2791mm
Roof: 0.5mm color-bond steel sheet roof
Floor: 18mm plywood board& fiber-cement board+1.5~3.5mm vinyl sheet &15mm bamboo flooring
Window: UPVC double glass tilt& swing window with Alu. Roller shutter
External door: Steel security door
Internal door: UPVC internal door& Aluminum frame sandwich panel door
External wall panel: 50/60/75/100/150mm sandwich wall panel
Internal wall: 50/60/75mm sandwich wall panel
Ceiling: 50mm EPS& rock-wool sandwich ceiling panel
Sanitary: White ceramic
Kitchen: MDF cabinet surface with lacquered paint and bench top with quartz stone
Electrical fittings: Wiring, power point, switch, light, circuit-breaker etc
Gutter: PVC gutter with down pipe.
Steel structure prefabricated container house features:
- Safty and reliable light steel flexible structural system
- Easy to transport, assemble and disassemble, repetitive to use
- Good and attractive apperance
- Waterproof, soud-insulated, heat preservation, seal, easy to clean and maintenant
- Any dimension and customized design are available
- Widely modal application, the office, conference room, dormitory, store, factory etc.
Steel structure prefabricated container house qualify certifications:
Steel structure prefabricated container house pictures:
