China Stainless Steel Plate Sandwich Panel Prefabricated House

House Accessaries

Elevation floor

design as client's detailed requirement

Watering system

custom made design and construction or as chinese national standard

Wiring system

custom made design and construction or as chinese national standard

Sanitary appliance

source china market for your needs

Furniture

source china market for your needs

Design technical data

Wind load

0.6KN/sqm

Roof dead load

0.35KN/sqm

Roof live load

0.5KN/sqm

Earthquake intensity

8 grade

Location temperature

-25ºC to 45ºC

Installation efficiency

Four skilled labors can assemble 40SQM house body in 8 hours.

Container transportation

Every 40ft sea container may load 150-180 SQM house body stuff.

The technical parameter of prefab house

NO.

Type

Name

Specification and Parameter

1

Product

Character

It can be disassembled repeatedly for 8 times under normal circumstances, and the utilization rate is up to 98% each time.

2

Dimension

Length

(n-2)×1224+2×1100mm (n is the amount of house, n=4,5,6...)

3

Width

according to request

4

Wall height/Ridge height

2450mm/3500mm (net height: 2450mm)

5

Standard Facilities

Groove footing

Steel of Z50×60×30mm material : Q235

6

Strut

H56×40 material: Q235

7

Roof girder

Top chord: section bar of 353 and square steel tube of 20×20 bottom bar: Q235

8

Roof panel groove

Steel of C40 material : Q235

9

Wall panel

EPS color steel sandwich panel or rock wool sandwich panel

10

Roof panel

EPS color steel sandwich panel or rock wool sandwich panel

11

Door

Color steel sandwich panel door or according to customer request

12

Window

Plastic steel window

13

Optional Facilities

Suspended ceiling

Mineral wool board ceiling, PVC ceiling, aluminum gusset ceiling

14

Floor

According to customer requirements

15

Electric work and plumbing

Plan offered (surface wiring)

16

Furniture and Appliances

According to customer requirements

17

Design Parameter

Live load of Roof

0.5 KN/square meter

18

Wind resistance

Grade-10 0.45KN/square meter(China standard)

19

Seismic Fortification Intensity

7

20

Transportation

A 40 feet container can load 300~350 square meters.

Main Material

Steel

Structure

and

Wall

Body

1.Wall structure frame

“U” shape steel frame

Roof

&

Ceiling

1.Steel roof truss

C80x40x15x2

Concrete frame

2.Roof panel

Light weight compound

sandwich panel

2.Exterior wall

Light weight compound

sandwich panel

3.Roof tile

Strip slate

3.Exterior wall

decorative board

Imitation brick texture Wall

4.Ceiling

Decorative Mgo board

or Gypsum board

4.Interior wall

Light weight compound

sandwich panel

Floor

1.Floor lateral support

Round steel or concrete

5.Interior wall

decorative material

Emulsion Paint or tile

2. Floor grider

"H"steel

6.Panel used in

Kitchen & toilet

Light weight compound

sandwich panel

3. Floor panel

Light weight compound

Sandwich panel

7. Corner post

Square tube or concrete

4.Floor decorative board

Tile or composite wooden floor panel

8.Wal Pilar

Rectangular tube or

concrete

5.Toilet ground tile

Polished tile
