Specifications
1.Qualified material.2.Reuse for numerous times.
3.Convenient package for shipping.
4.easy to assemble and disassemble.
Specifications of Container House/Home:
1) Container house has the international standard size 20ft HQ and 40ft HQ.
2) There are 7 types of wall panels for our container house and the inside finish can be steel sheet, aluminum sheet; MDF.
3) Roof, flooring and electricity system are all prefabricated before leaving factory.
4) The steel structure help the house resisting heavy winds of 210km/h and 8 grade earthquake.
5) 1-3 stories design can provide according to the customer's request.
6) The waterproof system on the roof makes the house a good sealing effect.
The details as follows:
Item |
Name |
Specification |
Dimension |
Length |
Exterior/interior: 5.950m/5.710m |
Width |
Exterior/interior: 2.310m/2.060m |
|
Height |
Exterior/interior: 2.740m/2.400m |
|
Weight |
1750kg per unit |
|
Standard accessory |
Floor |
Orlop wainscot: 0.4mm galvanized steel sheet. |
Structure: channel steel keel, Material:Q235. | ||
The girder of the keel are welded by two ends. | ||
Insulation fitting: EPS in a thickness of 30mm above the galvanized steel sheet. | ||
Waterproof bamboo-glue board in a thickness of 15mm for the bathroom and Plywood board in a thickness of 15mm for other rooms | ||
PVC floor sheet in a thickness of 1.5mm on the topside | ||
Permitted loading: 2.0KN/m2, Coefficient of thermal conductivity: K=1.1W/ m²K | ||
Roof |
Structure: box girder 120*80,Material:Q235 |
|
The topside wainscot: 0.5mm galvanized steel sheet. | ||
The purlins of the keel are welded by two ends. | ||
Insulation fitting: EPS in a thickness of 30mm above the galvanized steel sheet. | ||
Orlop wainscot: 5mm MDF laminated decorative panel | ||
Roof drainage: 4 PVC rainspout pipes, diameter 50mm in corner pillars. | ||
Permitted loading: 0.5 KN/m2, Coefficient of thermal conductivity: K=0.55W/ m²K | ||
Wallboard |
75mm Color steel sandwich panel, 0.5mm steel sheet surface, 29μm galvanized paint, inside white and outside silver-gray. |
|
Permitted loading: 0.6KN/m2, Polystyrene density: 15kg/m3, Coefficient of thermal conductivity: K=0.442W/mk | ||
Door |
SIP single door,size:800mm*2000mm, aluminum frame, 50mm thick EPS insulation foam, cylinder lock with 3keys. |
|
Window |
PVC sliding or casement window with fly screen, aluminium binding tape decorative , size:700mm*1000mm, 5mm glaze. |
|
Hallway |
Composite of framework and 2.5 thickness skid-proof steel board,Material:Q235 |
|
Stair |
Inclined girder is roolled channel pipe 160*50,steel board walk is 300 thickness skid-proof steel board,Material:Q235 |
|
Lamp |
2*30W double tube grilles lamp |
|
Switch |
two pieces siwtch |
|
Socket |
Two pieces of nine-hole socket,one piece of six-hole socket,two pieces of five-hole socket |
|
Breaker |
20A (fixed on the wallboard) |
|
Option |
Exhaust fan |
40W exhaust fan |
Partition |
50mm thickness double surface color steel sandwich panel board,white |
|
Window |
Color steel window,size:1702mm*991mm |
|
Door |
Color steel single and double door,size:1702mm*1920mm |
|
Stair awning |
Composite of square steel framework and transparent PVC board |
|
Resistance |
Bearing Load |
50kg/m2 |
Wind proof |
11 grade |
|
Fire proof |
B1 grade(fire-resistant materials) |
|
The earthquake resistance |
grade:7 degree |
Advantages of our new design prefab container house building:
1.Safe and reliable structure---earthquake proof
Light steel interior structure is the frame of our building, which meets the design requirements of steel structure. It can stand strong wind (150km/h) and 9 grade earthquake.
2.Easy to assemble and disassemble
Each worker can assemble 40-50 square meters everyday. 6 workers can finish 400 square meters prefab house in 2 days. It's especially suitable for emergency projects.
3.Various specifications are available
It has flexible layout according to the clients' idea
4. Reloadable and durable
It can be relocated up to 15 times. And it has 15 to 20 years durability
5.It's water proof, fire proof and moisture proof.
6.It is almost dry construction, does not use too much water.
8.Attractive appearance
We have many modern design and our engineer focusing on every details of the house in order to make the house nice.
9.Environment friendly and economical
All the materials are green and can be recycled.
Products show:
Certifications:
