Specifications
Steel structure prefabricated container houseattractive apperanc&flexible layout
easy installation
cost saving
ISO9001:2000
Steel structure prefabricated container house
Steel structure prefabricated container house specifications:
Item |
Name |
Specification |
Dimension |
Length |
Exterior/interior: 5.950m/5.710m |
Width |
Exterior/interior: 2.310m/2.060m |
|
Height |
Exterior/interior: 2.740m/2.400m |
|
Weight |
1750kg per unit |
|
Standard accessory |
Floor |
Orlop wainscot: 0.4mm galvanized steel sheet. |
Structure: channel steel keel, Material:Q235. | ||
The girder of the keel are welded by two ends. | ||
Insulation fitting: EPS in a thickness of 30mm above the galvanized steel sheet. | ||
Waterproof bamboo-glue board in a thickness of 15mm for the bathroom and Plywood board in a thickness of 15mm for other rooms | ||
PVC floor sheet in a thickness of 1.5mm on the topside | ||
Permitted loading: 2.0KN/m2, Coefficient of thermal conductivity: K=1.1W/ m²K | ||
Roof |
Structure: box girder 120*80,Material:Q235 |
|
The topside wainscot: 0.5mm galvanized steel sheet. | ||
The purlins of the keel are welded by two ends. | ||
Insulation fitting: EPS in a thickness of 30mm above the galvanized steel sheet. | ||
Orlop wainscot: 5mm MDF laminated decorative panel | ||
Roof drainage: 4 PVC rainspout pipes, diameter 50mm in corner pillars. | ||
Permitted loading: 0.5 KN/m2, Coefficient of thermal conductivity: K=0.55W/ m²K | ||
Wallboard |
75mm Color steel sandwich panel, 0.5mm steel sheet surface, 29μm galvanized paint, inside white and outside silver-gray. |
|
Permitted loading: 0.6KN/m2, Polystyrene density: 15kg/m3, Coefficient of thermal conductivity: K=0.442W/mk | ||
Door |
SIP single door,size:800mm*2000mm, aluminum frame, 50mm thick EPS insulation foam, cylinder lock with 3keys. |
|
Window |
PVC sliding or casement window with fly screen, aluminium binding tape decorative , size:700mm*1000mm, 5mm glaze. |
|
Hallway |
Composite of framework and 2.5 thickness skid-proof steel board,Material:Q235 |
|
Stair |
Inclined girder is roolled channel pipe 160*50,steel board walk is 300 thickness skid-proof steel board,Material:Q235 |
|
Lamp |
2*30W double tube grilles lamp |
|
Switch |
two pieces siwtch |
|
Socket |
Two pieces of nine-hole socket,one piece of six-hole socket,two pieces of five-hole socket |
|
Breaker |
20A (fixed on the wallboard) |
|
Option |
Exhaust fan |
40W exhaust fan |
Partition |
50mm thickness double surface color steel sandwich panel board,white |
|
Window |
Color steel window,size:1702mm*991mm |
|
Door |
Color steel single and double door,size:1702mm*1920mm |
|
Stair awning |
Composite of square steel framework and transparent PVC board |
|
Resistance |
Bearing Load |
50kg/m2 |
Wind proof |
11 grade |
|
Fire proof |
B1 grade(fire-resistant materials) |
|
The earthquake resistance |
grade:7 degree |
Steel structure prefabricated container house technical parameters:
1.Wind resistance: grade 11 (wind speed ≤111.5km/h)
2.Earthquake resistance: grade 8
3.Live load capacity of roofing: 0.5kN/m2
4.External and internal wall heat transmission coefficient: 0.35Kcal/m2hc
5.Usage: offices, dormitory, hotel, remote building site, portable toilet and etc.
6.Package: flat package, all components are well wrapped.
Steel structure prefabricated container house characteristics:
(1) With good appearance and can designed with customers' requirement.;
(2) Have strong earthquake resistance, high wind resistance , sound-insulated and anti-distortion ability;
(3) With good thermal insulation, and waterproof ability;
(4) Repetitive to use and Produce few construction trash ;
(5) Cost saving and transportation convenient( each 4 sets of container houses can be loaded in one standard shipping container).;
(6) Service life is long, can reach up to 15-20 years.
Steel structure prefabricated container house qualify certifications:
Steel structure prefabricated container house pictures:
