Specifications
Steel structrure prefabricated houseEasy Installation
Waterproof, Acoustic & Insulative
Honest & Efficients
ISO 9001:2000
China low cost steel structure prefabricated labour house
Steel structure prefabricated house specifications:
Size |
External | 6058mm(L)* 2438mm(W)* 2896mm(H) |
| Internal | 5820mm(L)* 2200mm(W)* 2680mm(H) | |
| Color | Standard: White. (May be customized as per your requirements) | |
| Steel Frame | 4mm (Hot-galvanized) | |
| Wall | 60mm EPS / PU / Rock wool sandwich panel | |
| Roof | 1st layer | 40mm EPS / PU / Rock wool sandwich panel |
| 2nd layer | 150mm thermal insulation | |
| 3rd layer | Galvanized roof tile | |
| Floor | 1st layer | Hot-galvanized steel sheet |
| 2nd layer | 75mm insulation Foam board | |
| 3rd layer | 18mm plywood base panel | |
| 4th layer | 4th layer: Vinyl Floor | |
| Door (1pc) | Steel security door (with keys): | |
| Size- 840mm*2000mm (May be customized) | ||
| Window (2pcs) | Sliding PVC windows: Size--800mm*1100mm (May be customized) | |
| Electricity | Distribution box*1 | |
| Circuit break*1 | ||
| Ceiling Lights*2 | ||
| Sockets*3 | ||
| Switch*1 | ||
| Local standard cables | ||
| Water pipes | Local standard supply and drainage pipes | |
| Usage | Accommodation, office, living room, hotel, meeting room, dormitory, shop, booth, toilet, storage, kitchen, shower room and so on. | |
Steel structure prefabricated house features:
1:steelQ235.Q345 and etc
2:joints with high strength bolts
3;increasing area efficiency by 10%-15%
4:freely cutting for the big space
5:compound wall materials , pipe and line can be easily disposed
Steel structure prefabricated house characteristics:
1. Easy to assemble and disassemble: The house can be assembled and disassembled for dozens of times and can be reused many times. And the assenmbling only needs simple tools without any power source. Plugs and screws are all the needs to connect the pieces of the houses.
2. Strong structure: It adopts steel frame structure. Thus, it is stable according to the code of building structure.
3. Durable: The steel frame parts are all processed with anti-corrosion coating and it can be used at least for 20 years.
4. Heat-insulation: The walls and roof are made of color-coated steel sandwich panels (EPS, XPS, PU or Rock Wool) which is knowns for its food heat-insulating and fire proof performance.
PS: The wall can also be made of autoclaved lightweight panel which is a better material for walls.
5. Enviroment protection: The design of the house is resonable. And it is easy to assemble and disassemble.
6. Others: The design of the house can be customized. We put the benefits of the customer in the first place.
Steel structure prefabricated house advantages:
1.safe and reliable structure---earthquake proof
light steel structure is the frame of our building,which meets the design requirements of steel structure.
2.Easy to install and disassemble
It just need simple tools to assemble.Each worker can assemble 30-40 square meters everyday.6 workers can
finish 400 square meters prefab house in 2 days.It's especially suitable for emergency projects.
3.Various specifications are available
has flexible layout according to the clients' idea
4.Relocatable and durable
It can be relocated up to 10 times.And it has 15 to 20 years durability
5.It's water proof,fire prevention and moisture proof.
6.The light steel structure is reliable to meet strong wind and 7 grade earthquake.
7.It is almost dry construction,dose not use too much water.
8.Attractive appearance
because prepainted steel sheet is adopted,the whole structure is handsome.
9.Environment friendly and economical
reasonable design makes it reusable.The reusable character makes it environment friendly and economical
Steel structure prefabricated house qualify certifications:
Steel structure prefabricated house pictures:
call us if you are interested in our products
Mobile number:86 13355452917
