High light transmission LED light diffusion polycarbonate sheet
1. Picture of polycarbonate light diffusion sheet
2. Description of polycarbonate light diffusion sheet
PC llight diffusion sheet has the excellence of high impact sttrength ,bear the high temperature and aging , simply installation ,which the traditional advertising panel (PMMA) does not have .PC advertising panel can keep the color and luster fresh ,and has the better weather resisitance .
Product Features
- astigmatism effect ,can not see the backlight
- 10-year gurantee
- Good light transmission
- good weather resistance and UV protection
- very high impact strength
- good effect of soundproof
- Light weight
- Simply installed
- certified by ISO9001:2000
- combing with LED light can get the effect of color change
Product specification
| Thickness(mm) | stardard length(mm) | standard Length(mm) | Specific Gravity | Standard Colors |
| 1.5 | 1200-2100 |
6000mm 4mm>no Limited |
1.2 |
clear green blue green-blue brown opal |
| 1.8 | ||||
| 2 | ||||
| 2.5 | ||||
| 3 | ||||
| 4 | ||||
| 5 | ||||
| 6 | ||||
| 8 | ||||
| 10 | ||||
| 12 |
Technical features:
1) Impact strength: 850J/m ,the impact strength of solid PC sheets is 250 times
that of glass, 20-30 times of PMMA sheet
2) Light transmission: 80%-90% for different thickness of clear color
3) UV resistance:50μm thickness UV layer, the sheet can filter 99% ultraviolet radiation in sunlight
4) Specific gravity: 1.2 g/cm
5) Coefficient of thermal expansion: 0.065 mm/moC
6) Service temperature: -40oC to 120oC
7) Heat conductivity: 2.3-3.9 W/m2 oC
8) Tensile strength: >60N/mm2
9) Flexural strength: 100N/mm2
10) Modulus of elasticity: 2,400mPa
11) Tensile street at break: >65mPa
12) Elongation at break: >100%
13) Specific heat: 1.16J/kgk
14) Heat deflection temperature: 140oC
15) Soundproof index:4mm thickness--27dB,5mm--28dB,6mm--29dB
Application
- advertising light panel
- LCD optical panels
- shop sign, outdoor billboard
1. Trade item of product
| Payment | L/C,T/T,Western Union |
| Port | Shanghai or Ningbo |
| MOQ | 3000kg |
| Supply Ability | 10000tons per year |
| OEM | Accept |
| Delivery | 7-10days after reciving your deposit for a 20GP |
2. Packing of product
1. Introduction of company
- professional manufacturer of polycarbonate sheet, founded in 2003
- total buliding size: 10,000sqm
- staff number: about 100
4. Why choose us
- GENSIN ONLY PROVIDE THE GRADE A POLYCABRONATE SHEET !
- WE HAVE 12 PRODUCTION LINES FOR DIFFERENT POLYCARBONATE SHEETS, GENSIN OWNS ONE UNION MACHINE.
- GENSIN HAS A GREAT SALES TEAM, FEEL FREE TO CONTACT US !
