Polycarbonate advertising light panel
PC advertising panel has the excellence of high impact sttrength ,bear the high temperature and aging , simply installation ,which the traditional advertising panel (PMMA) does not have .PC advertising panel can keep the color and luster fresh ,and has the better weather resisitance .
Product Features
- Astigmatism effect ,can not see the backlight
- Combing with LED light can get the effect of color change
- Good weather resistance and UV protection
- Very high impact strength
- Good light transmission
- Light weight, Simply installed
- Meet different fire protection standard
Technical features:
1) Impact strength: 850J/m ,the impact strength of solid PC sheets is 250 times
that of glass, 20-30 times of PMMA sheet
2) Light transmission: 80%-90% for different thickness of clear color
3) UV resistance:50μm thickness UV layer, the sheet can filter 99% ultraviolet radiation in sunlight
4) Specific gravity: 1.2 kg/m³
5) Coefficient of thermal expansion: 0.065 mm/moC
6) Service temperature: -40oC to 120oC
7) Heat conductivity: 2.3-3.9 W/m2 oC
8) Tensile strength: >60N/mm2
9) Flexural strength: 100N/mm2
10) Modulus of elasticity: 2,400mPa
11) Tensile street at break: >65mPa
12) Elongation at break: >100%
13) Specific heat: 1.16J/kgk
14) Heat deflection temperature: 140oC
15) Soundproof index: 4mm thickness--27dB, 5mm--28dB, 6mm--29dB
Application
- Advertising light boxes , signs
- Outerdoor billboards
- LED lighting
- Guides system
- Light cover
