Home > Manufacturing & Processing Machinery > Glass Machine > Glass Production Line > CE Approved Size Customized Industrial Intelligent Control Glass Melting Oven Forced Convection Flat/Curved Tempered Glass Stove

CE Approved Size Customized Industrial Intelligent Control Glass Melting Oven Forced Convection Flat/Curved Tempered Glass Stove

China Glass Tech Co., Ltd.
CE Approved Size Customized Industrial Intelligent Control Glass Melting Oven Forced Convection Flat/Curved Tempered Glass Stove thumbnail-1
CE Approved Size Customized Industrial Intelligent Control Glass Melting Oven Forced Convection Flat/Curved Tempered Glass Stove photo-1
US$ 17,800 - 36,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Machine Type:
Glass Tempering Furnace
Production Capacity:
15-18 loads/h
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Machine Type Glass Tempering Furnace
Production Capacity 15-18 loads/h
Place of Origin Shandong, China
Brand Name HUAXING
Model Number Tempered Glass Stove
Voltage 3 phases, 380v, 50Hz or as per your requirements
Power(W) 792000
Dimension(L*W*H) as per your request
Weight about 3220KG
Certification CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Double direction
2.Ceramic rollers and rubber rollers
3.Beckhoff intelligent control
4. high output
5.Certification: CE

CE Approved Size customized Industrial intelligent control glass melting oven Forced Convection Flat/Curved Tempered Glass Stove

1.Brief introduction

Tempering glass machinery is used for producing flat or bent tempered glass for windows, doors, shower cabins and kitchen,cartain wall,etc.

 2.Picture of glass machinery

CE Approved Size customized Industrial intelligent control glass melting oven Forced Convection Flat/Curved Tempered Glass Stove



3.Technical parameter of glass machinery

type

Max. size(mm)

Min. size(mm)

Thickness (mm)

Capacity (m2/h)

Power supply capacity(KVA)

HP1506

1500*600

90*90

3-8

14

≥100

HP1508

1500*800

100*100

3-12

18

≥150

HP2010

2000*1000

100*100

3-12

30

≥200

HP2012

2000*1200

120*120

3-12

37

≥250

HP2512

2500*1200

120*120

3-12

46

≥250

HP2515

2500*1500

150*250

3-19

57

≥315

HP3015

3000*1500

150*250

3-19

69

≥400

HP2518

2500*1800

150*250

3-19

69

≥400

HP3018

3000*1800

150*250

3-19

83

≥400

HP3618

3660*1800

150*250

3-19

99

≥500

HP3021

3000*2100

150*250

4-19

96

≥500

HP3621

3660*2100

150*250

4-19

116

≥600

HP4221

4200*2100

150*250

4-19

135

≥700

HP3624

3660*2440

150*250

4-19

132

≥630

HP4224

4200*2440

150*250

4-19

154

≥800

HP5024

5000*2440

150*250

4-19

184

≥1000

HP6024

6000*2440

150*250

5-22

220

≥1000

HP5028

5000*2800

200*300

5-22

214

≥1000

HP6028

6000*2800

200*300

5-22

257

≥1250



4.Processable glass type

1)Clear float glass   2)Reflective glass   3)Low-E glass   4)Patterned glass   5) color float glass 6)single face silk screen glass   7)super white pattern glass

CE Approved Size customized Industrial intelligent control glass melting oven Forced Convection Flat/Curved Tempered Glass Stove



5.Factory pictures

Welcome to visit our factory.

 CE Approved Size customized Industrial intelligent control glass melting oven Forced Convection Flat/Curved Tempered Glass Stove

6.Advantages of toughened glass machinery

a.5mm H style steel for main frame

b.3mm steel for side board

c. servo motor

d.siemens system

e.VSV ceramic roller

f. Schneider transducer

g.Aeop insulation cotton

h.ABB electrical machine

i.Cr15NI60 furnace heating wire

7.Exhibition pictures

Every year we attend exhibitions both at home and abroad.



CE Approved Size customized Industrial intelligent control glass melting oven Forced Convection Flat/Curved Tempered Glass Stove



8.Customers visiting pictures

We have already export our products all over the world. Every year, many customer come to visit us and establish long business with us.



CE Approved Size customized Industrial intelligent control glass melting oven Forced Convection Flat/Curved Tempered Glass Stove
